Parts Included
Frame:
A Side Frames
A Bars
A Bars
A Side Base Frames
Poly Tray
Lights :
Light Fixture Hood
Ballasts
T- Light Tubes
' Light Cord
Link Cord
Hardware: Ball Chains
Chain Connectors
Large Split Rings
Small Split Rings
Chain Grips
Bolts
End Plugs
With the help of one other person, you can assemble the
Tabletop SunLite
Garden in less than an hour. The only tools
®
you'll need are a Phillips screwdriver, a hammer or rubber
mallet and pliers.
Frame Assembly
Step . Lay out all Frame Parts on a flat, clean surface.
Step . Connect an A Side Base Frame to the end of each
A Bar using two Phillips-head bolts (Figure ). Repeat
this step to connect the second A Side Base Frame to the
other end of the A Bars. Do not fully tighten the bolts on
the frame until Step .
Step . Connect the A Side Frames to the A Side Base
Frames by placing a Phillips-head bolt up through the hole
in the underside of each A Frame. Make sure the pre-
drilled guide hole in the A Side Frame is positioned near
the top. (Figure ).
Step . Insert a Phillips-head bolt through the top bolt hole
of the A Side Frame into the end of the A Bar (Figure ,
on next page). Do this on both ends of the Bar. Now fully
tighten all the bolts on the frame.
-
Standard Tabletop SunLite
Qty.
over please
Garden
®
Figure
Figure
A
A
A
Bolt
A
Bolt
Bolt
S Rev /
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Gardener's Standard Tabletop SunLite Garden
Summary of Contents for Gardener's Standard Tabletop SunLite Garden
- Page 1 Standard Tabletop SunLite Garden ® Figure Parts Included Qty. Frame: A Side Frames A Bars A Bars A Side Base Frames Poly Tray Lights : Light Fixture Hood Ballasts T- Light Tubes ' Light Cord Link Cord Hardware: Ball Chains Chain Connectors Large Split Rings Small Split Rings...
