FOREWORD
Keys ................................................................. 2 - 1
Main battery disconnect switch....................... 2 - 2
Fuel tank filling................................................. 2 - 2
Controls and instrument panels ...................... 2 - 3
L.H. side control panel..................................... 2 - 4
Cruise control switches ................................... 2 - 6
Dashboard (without tachograph) .................... 2 - 9
Dashboard (with tachograph) ....................... 2 - 10
L.H. lower switch panel ................................. 2 - 15
R.H. lower switch panel................................. 2 - 16
R.H. console .................................................. 2 - 16
Detroit diesel PRODRIVER
R.H. lateral console ....................................... 2 - 20
Automatic transmission ................................. 2 - 21
Manual transmission ..................................... 2 - 23
Steering column controls............................... 2 - 24
Foot-operated controls .................................. 2 - 25
column ........................................................... 2 - 26
Entrance door ................................................ 2 - 26
Seats.............................................................. 2 - 27
Driver's seat................................................... 2 - 28
Seat belts....................................................... 2 - 28
Passenger seats............................................ 2 - 29
Tour guide seat.............................................. 2 - 29
Mirrors............................................................ 2 - 29
Exterior compartments (XL-40)..................... 2 - 31
Exterior compartments (XL-45)..................... 2 - 32
Engine compartment doors........................... 2 - 33
Engine air intake ducts.................................. 2 - 33
Fuel tank filling door ...................................... 2 - 33
Entrance door ................................................ 2 - 33
1 - 1
2 - 1
TM
controls .......... 2 - 17

TABLE OF CONTENTS

XL Series Motorcoach
TABLE OF CONTENTS
Engine compartment components ................2 - 34
Baggage compartment ..................................2 - 35
Spare wheel & tire compartment ...................2 - 35
doors...............................................................2 - 36
Service doors .................................................2 - 36
main power compartment ..............................2 - 36
Battery compartment......................................2 - 37
Interior compartments....................................2 - 37
Lavatory..........................................................2 - 37
Parcel racks....................................................2 - 38
Safety equipment compartment ....................2 - 38
Accessories....................................................2 - 38
Preheating system timers (auxiliary) .............2 - 43
SAFETY
Brakes ..............................................................3 - 1
Antilock braking system (ABS) ........................3 - 2
Air system emergency fill valve .......................3 - 2
Back up alarm ..................................................3 - 3
Kneeling system...............................................3 - 3
Hi-buoy system ................................................3 - 3
Low-buoy system .............................................3 - 3
Emergency exits ..............................................3 - 4
Day time running lights ....................................3 - 5
Fog lights..........................................................3 - 5
Horns ................................................................3 - 5
Alarm system ...................................................3 - 6
Safety equipment .............................................3 - 6
Safety precautions...................................3 - 7
Defensive driving..............................................3 - 8
i
