quick start guide
English
Product features
Surround Multi Flow
A center-positioned fan and
ducts with multiple flow
effluences provide uniform
cooling for each shelf and fresh
food compartment corners.
Twin Cooling System
The refrigerator and the freezer
have two evaporators. Given this
independent system, the freezer
and the refrigerator are cooled
individually and more efficiently.
Food odor from the refrigerator
does not affect food in the
freezer due to separate air flow
circulation.
Electronic control from
outside of Pantry Cover
The Cool Select Pantry is a full
width drawer with an adjustable
temperature control to help keep
food fresh longer.
RFG293HA
Secure Auto Close Door
System
•
Secure Auto Close Door System
•
Cool tight doors
•
Energy saving
•
Prevents condensation on fridge
doors
Easy Handle System
•
Ez-open Freezer Door
•
Ergonomic Door Design
Super Extended Drawer
The upper drawer in the freezer
comes out automatically when
you open the freezer door and
can be pulled out all the way to
the Tilting Pocket.
Advertisement
Table of Contents
Related Manuals for Samsung RFG293HABP
Summary of Contents for Samsung RFG293HABP
-
Page 1: Product Features
quick start guide English Product features Surround Multi Flow A center-positioned fan and ducts with multiple flow effluences provide uniform cooling for each shelf and fresh food compartment corners. Twin Cooling System The refrigerator and the freezer have two evaporators. Given this independent system, the freezer and the refrigerator are cooled individually and more efficiently. -
Page 2: The Installation Space
First thing! Make sure that you can easily move your Refrigerator to its final location by measuring doorways (both width and height), thresholds, ceilings, stairways, etc. The following chart details the exact height and depth of Samsung French Door Refrigerator. Depth... -
Page 3: Operating Your French Door Refrigerator
Operating your French Door Refrigerator uSING THE CONTROL PANEL & DISPLAy Ice off Button Press the Ice Off button ( ) , if you don’t want to make more ice. The icon ( stops making ice. In this case of following, it is recommended to stop making ices. - There are enough ices in the ice bucket. - Page 4 Operating your French Door Refrigerator uSING THE CONTROL PANEL & DISPLAy Power Freeze Button Press the Power Freeze button ( Freezer. The icon ( ) will light up and the inside temperature of the Freezer will decrease for about two and a half hours.
-
Page 5: Cooling Off Mode
Fridge Button Press the Fridge button ( ) repeatedly until the desired temperature is shown in the display ( Whenever you press the button, the temperature will move 2°F degrees each push and you can set the temperature between 46°F and 34°F. Five seconds after the new temperature is set, the display will again show the actual current freezer temperature until the new temperature is selected. - Page 6 Operating your French Door Refrigerator uSING THE CONTROL PANEL & DISPLAy Filter The Filter light ( ) lets you know when it is time to change your water filter cartridge. When the filter indicator lights up red, it is time to change the filter. Changing the filter on time provides you with the freshest, cleanest water from your refrigerator.
- Page 7 For a replacement water filter, you can visit your local home improvement center or contact the Samsung Parts distributor. Be sure the replacement water filter has the SAMSUNG logo on the box and on the water filter. Link : http://www.samsungparts.com...
-
Page 8: Name Of Each Component
Names and basic functions NAMe OF eACH COMPONeNT ➋ ➌ ➍ ➎ ➏ 1. Light 2. Vertical Hinged Section 3. Vegetable & Fruit Drawers 4. FZ Ice-Maker 5. Ice Bucket ➊ 6. Tilting Pocket 11. Quick-Space Glass Shelf 7. Door Closer 12. -
Page 9: Troubleshooting
Troubleshooting PROBLEM The refrigerator does not • Check that the power plug is properly connected. • Check the set temperature on the digital display is warmer than freezer or fridge work at all or it does not chill sufficiently. • Set the refrigerator colder. •...
