POE606 - Quick Start Guide
The POE606 is a power 1Gbps 4 way switch that can supply up to 71W of power per port.
Designed for higher load POE CCTV Equipment such as PTZs or you can use it to power other devices
such as PoE extenders.
Because of the very high 71W output per port the power supply is external to the switch supplied with
it.

Setup Options

Option 1
To power IP Cameras using the PoE switch
then connect the IP Cameras using
CAT5e/CAT6 Ethernet Cable, for longer
distances we recommend using high
quality cable, with solid copper cores.
Option 2
Provide network infrastructure to PoE and
non-PoE Devices, like computers, and other
Network devices.
Quick Start Guide - qPOE606
1
Powerful High Load Gigabit Switch - 71W per port
User Information
·
The PoE Switch must be installed in a clean, dry
environment where it will not be exposed to high
temperatures, moisture or excessive dust.
·
Do not touch the PoE Switch or any of its connections with
wet hands.
·
Ensure the power is switched off if the PoE Switch is not in
use for a long period of time.
·
There are no user serviceable parts in the PoE Switch and
opening or attempting to repair the product will void the
warranty.
·
Only use the PSU originally supplied with the product.
·
Do not install or use the device if the power cable is
damaged.
