ScatterBox HDMIMule HDM210 Manual

HDM210 HDMI KVM TX/RX
This HDMI KVM (Keyboard, Video and
Mouse) switch can control a DVR or NVR
from a remote location up to 100 metres on
CAT5 and will also transmit IR signals. It can
also control one or more computers from a
single keyboard or mouse, and view them with
audio on a single HDMI monitor.
The HDM210 consists of an HDM182
transmitter and an HDM192 receiver. These can
be purchased individually as one transmitter can
control a number of receivers.
Example of use
The DVR/NVR could be installed in a locked server room and a monitor and mouse installed
in a reception area where the DVR/NVR pictures could be viewed and mouse access available
to the DVR. An IR facility can also be used to use a remote from the monitor end to control
the DVR.
List of HDM210 Components
1 x HDM182 Transmitter
1 x HDM192 Receiver
2 x 5v DC 2A Power Supplies
1 x IR Transmitter
1 x IR Receiver
