Summary of Contents for Dometic miniCool
- Page 1 All manuals and user guides at all-guides.com miniCool INSTRUCTION for USE ABSORPTION-REFRIGERATOR EA 330 (L) EA 355 (L) English Type H20 / 60 T.D. 07/2003 821 2675 -51...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com INTRODUCTION FOR YOUR SAFETY 2.1 Warnings and Safety Advice 2.2 Coolants WARRANTY AND CUSTOMER SERVICE INSTALLATION 4.1 The Purpose of this Manual 4.2 Tools/Materials Required 4.3 Unpacking 4.4 Cleaning 4.5 Installation 4.6 Securing 4.7 Connecting the Device to the Electricity Supply 4.8 Changing the Sliding Hinge... -
Page 3: Introduction
Ÿ The minibar is not suitable for the proper storage of medications. The miniCool must be installed in such a way that accidental contact with Ÿ the cooling unit (which heats up when in use) is impossible. -
Page 4: Installation
Depending on the model, the following parts can be found in the miniCool : Cleaning Before operating the miniCool, we recommend you clean it both inside and outside. Use a soft cloth, lukewarm water and a mild detergent. Ÿ... -
Page 5: Installation
All manuals and user guides at all-guides.com Installation 200 cm² 20 mm IMPORTANT: Please follow the installation details below carefully. Guarantee is valid for products installed as described only. 1. The refrigerator must be level both directions 2. There sould be 20mm clearance to the wall 3. -
Page 6: Securing
All manuals and user guides at all-guides.com Securing EA 330 The miniCool must be screwed onto the cupboard using the lower hinges. 1. Tighten screw. 2. Put on cap. Connecting the Device to the Electricity Supply The device must be connected to a properly earthed socket in line with Ÿ... -
Page 7: Changing The Sliding Hinge
If the fuse cover-carrier is lost, a replaceement can be obtained from the Dometic service Shops. The fuse cover/carrier must be of the same colour as that of the coloured insert in the base of the plug. -
Page 8: Changing The Doorhang
All manuals and user guides at all-guides.com Changing the Doorhang (possible with EA 330) -
Page 9: Instruction For Use
The electronics carries out a leakage test after every defrosting period ( every 24 hrs) by measuring the temperature at the evaporator by means of a second sensor. If a leakage is detected, the miniCool is shut off by the electronics. Evaporator sensor Air sensor... -
Page 10: Automatic Door Control (Adc)
Using a red dot in the display window (A, point 3), the ADC shows that the miniCool´s door has been opened. 1. Open the miniCool, check its contents and - if applicable- stock it up again. 2. Close the miniCool. -
Page 11: Interior Light
Changing : 1. Pull out the 2. Press out 3. Remove defective mains plug. reflector disk. LED-board. 4. Insert new LED-board. 5. Clip reflector disk back in. To obtain spare bulbs, please contact your Dometic Service Centre. -
Page 12: Environmental Advice
If possible, always store pre-cooled goods. Ÿ Do not expose the miniCool to direct sunlight and do not place it close Ÿ to a source of heat. An unobstructed air circulation in the fridge aggregate must be Ÿ... -
Page 13: Check List
All manuals and user guides at all-guides.com 5.11 Check List Problem: No cooling (the aggregate at the back of the device is cold). Possible Cause Self Help Authorised Service a.) The thermostat is set to “0”. a.) Set temperature control to middle position. -
Page 14: Technical Data
All manuals and user guides at all-guides.com 5.12 Technical Data Model EA 330 EA 355 Built-in Freestanding Casing Metal Wood Gross Contentss (litres) cooled / uncooled 30 / - 35 / 20 Dimensions (mm) (H x W xD) 522x384x412 780x420x445 Electric Rating (W) Power Consumption kWh / 24h*... - Page 15 All manuals and user guides at all-guides.com Dometic GmbH In der Steinwiese 16 D-57074 Siegen Phone: +49-(0) 271 / 692 0 Fax: +49-(0) 271 / 692 300 www.dometic.de/minibar www.dometic.com...
