Contec RSS-25M/9F User Manual

RS-232C Connection Conversion Straight Cable

The RSS-25M/9F is a cable for connecting a 9-pin D-SUB connector on the RS-232C board with a
mating connector of a device to be connected.

External Dimensions

15.0mm
9
5
6 1

Specifications

Item
9-pin D-SUB female connector
Connector
25-pin D-SUB male connector
Cable 9 core shield cable
Weight 160g

Notes!

- Do not strike or bend the product. Otherwise, the product may malfunction, overheat, cause a
failure or breakage.
- Do not insert or remove the connector while the power is turned on to the PC. Failure to observe
this precaution may cause malfunction, overheating.
- The specifications of this product are subject to change without notice for quality improvement.
Even when using the product continuously, be sure to read the manual and understand the contents.
- Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for any results of using the product.
- All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
1
(25M→9F, 1.8m)
RSS-25M/9F
User's Guide
CONTEC CO.,LTD.
44.8mm 1800mm
Conductor size: AWG28 Conductor composition: 7pcs/0.127mm UL2919
Specification
Thumb screw: UNC#4-40 (Inch screw)
Thumb screw: UNC#4-40 (Inch screw)
15.3mm
51.0mm
13
1
RSS-25M/9F
25
14
