Connecting the Pipe to a Ceiling Adapter
IMPORTANT!
Connect this 1.5" NPT threaded
may disconnect the parts and may cause injury or property damage.
pipe end to the ceiling plate
1
To connect the pipe to a ceiling adapter,
twist the male threaded end into the
female thread of the adapter.
Connect this 1.5" NPT
threaded pipe end to
(EE) x 4
the mount head
OR
For extension
Pipe Connector
longer than 3 ft
connect two or
more pipes
together with a
pipe connector
(not included).
Allen Key
(II)
Do not loosen screws all the way when making adjustments, this
Ceiling
Vaulted Ceiling Adapter
(not included)
(DD) x 2
Allen Key
OR
(EE) x 2
These screws are only included
with your ceiling adapter
or pipe connector.
2
Using allen key (II), tighten screws onto the
pipe and secure the position.
Cable Management
(B)
Take out the top piece on the
(DD) x 4
cover plate (B) and push
the cord through the opening.
3"~3' 1.5" NPT THREADED PIPE
(II)
QG-PRO-PM-3IN-B / W
QG-PRO-PM-6IN-B / W
QG-PRO-PM-1FT-B / W
QG-PRO-PM-2FT-B / W
QG-PRO-PM-3FT-B / W
CAUTION!
363kg
Do not exceed the maximum rated weight
(800lbs)
specified. Otherwise, serious injury or
RATED
property damage may occur.
5 Year Limited Warranty
5 Year Limited Warranty
Version June 2016
Version June 2016
© 2016
QualGear LLC
