Revision: 1.0
USER MANUAL
Secure 4 Port COMBO KVM Switch
with CAC Port and 4K Ultra-HD Support
CK4-HPD404C
4-Port Secure Pro SH DVI, SH HDMI and DH DP KVM
w/audio and CAC, PP 4.0
Designed and Manufactured in the USA
Release Date: July 21, 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CK4-HPD404C and is the answer not in the manual?

Questions and answers

Related Manuals for SEKURYX CK4-HPD404C

Summary of Contents for SEKURYX CK4-HPD404C

  • Page 1 Release Date: July 21, 2021 USER MANUAL Secure 4 Port COMBO KVM Switch with CAC Port and 4K Ultra-HD Support 4-Port Secure Pro SH DVI, SH HDMI and DH DP KVM CK4-HPD404C w/audio and CAC, PP 4.0 Designed and Manufactured in the USA...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TECHNICAL SPECIFICATIONS_____________________________________________________ WHAT’S IN THE BOX?____________________________________________________________ SECURITY FEATURES____________________________________________________________ FRONT AND REAR_______________________________________________________________ INSTALLATION__________________________________________________________________ CAC INSTALLATION: COMMON ACCESS CARD, SMART CARD READER__________________ CAC PORT CONFIGURATION______________________________________________________ AUDITING: Dumping the Event Log via User Menu Options________________________________ RESET: Restore Factory Default_____________________________________________________ LED’s BEHAVIOR________________________________________________________________ SYSTEM OPERATION____________________________________________________________ TROUBLESHOOTING____________________________________________________________ TECHNICAL SUPPORT___________________________________________________________...

  • Page 3: Technical Specifications

    TECHNICAL SPECIFICATIONS VIDEO Format DVI-I Dual Link, DVI 1.0, DVI-D, XVGA, DisplayPort1.2, HDMI2.0 (8) DisplayPort 20-pin; Host Interface (4) HDMI 19-pin; (4) DVI-I 29-pin (female) / DVI-D (2) DisplayPort 20-pin; User Console (1) HDMI 19-pin; Interface (1) DVI-I 29-pin (female) / DVI-D Max Resolution 3840 x 2160 @ 30 Hz 5 volts p-p (TTL)

  • Page 4: What's In The Box

    Check if any of the front panel port selection buttons are jammed. In this case, release the jammed button and recycle the power. CK4-HPD404C Rear Panel Secure COMBO KVM Switch with Dedicated CAC Port and 4K Ultra-HD Support...

  • Page 5: Installation

    INSTALLATION SYSTEM REQUIREMENTS 1. SEKURYX Secure PSS is compatible with standard personal/portable computers, servers or thin- clients, running operating systems such as Windows or Linux. 2. The peripheral devices that are supported by the KVM are listed in the following table:...
  • Page 6 INSTALLATION (Continued) 1. Ensure that power is turned off or disconnected from the unit and the computers. 2. Use a DisplayPort, HDMI and DVI cable to connect the DisplayPort, HDMI and DVI output port from each computer to the corresponding DP IN, HDMI IN and DVI IN ports of the unit. 3.
  • Page 7 INSTALLATION (Continued) EDID LEARN: The KVM is designed to learn the connected monitor’s EDID upon power up. In the event of connecting a new monitor to the KVM, a power recycle is required. The KVM will indicate to the user the EDID learn process by flashing the front panel’s LEDs. Port one green and push button blue LEDs will both begin to flash for about 10 seconds.

  • Page 8: Cac Installation: Common Access Card, Smart Card Reader

    CAC (COMMON ACCESS CARD, SMART CARD READER) INSTALLATION The following steps are intended for the system administrator or IT manager only. If you have the optional CAC ports there will be 4 ports on a 4 host ports KVM. CAC connection to the computer requires a USB cable connection separate from the keyboard and mouse.

  • Page 9: Auditing: Dumping The Event Log Via User Menu Options

    The Event Log is a detailed report of critical activities stored in the KVM memory. A comprehensive feature list and guidance for Administration and Security Management Tools can be found in the Administrator’s Guide available for download from: http://sekuryx.com/documentation/. To view or dump the Event Log: 1.

  • Page 10: Led's Behavior

    Monitor is not connected permanently disabled. Please Monitor is connected contact SEKURYX technical support at Flashing EDID problem – Learn EDID to fix the problem support@sekuryx.com. User Console Interface – CAC LED: If all Front Panel LED’s are on and not...

  • Page 11: System Operation

    Check if the USB cables connecting the unit and the computers are properly connected. • Make sure the CAC port is enabled. TECHNICAL SUPPORT For product inquiries, warranty questions, or technical questions, please contact info@sekuryx.com. Secure COMBO KVM Switch with Dedicated CAC Port and 4K Ultra-HD Support...

  • Page 12: Limited Warranty Statement

    Customer is responsible for maintaining proof of date of purchase. SEKURYX limited warranty covers only those defects which arise as a result of normal use of the product, and do not apply to any: a.
  • Page 13 NOTICE The information contained in this document is subject to change without notice. SEKURYX makes no warranty of any kind with regard to this material, including but not limited to, implied warranties of merchantability and fitness for particular purpose. SEKURYX will not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material.
