Model:
YSA1203601
YSA1203602
Note:
Furniture grade construction consisting of a Solid wood Frame
U-shaped drawer for maximum storage
Full extension, soft close drawers with dovetail construction
Wall mount bracket included
Top
15"
Front
SPECIFICATION SHEET
SPECIFICATION SHEET
36"
3⅛"
12 ⁄ "
12¼"
3 ⁄ "
4¾"
36"
15"
Side
www.maykke.com
36" Dani Vanity White
6"
REV. 12292015
Advertisement
Related Manuals for Maykke YSA1203601
Summary of Contents for Maykke YSA1203601
- Page 1 SPECIFICATION SHEET Model: 36" Dani Vanity White YSA1203601 YSA1203602 Note: Furniture grade construction consisting of a Solid wood Frame U-shaped drawer for maximum storage Full extension, soft close drawers with dovetail construction Wall mount bracket included 36” 3⅛” 15” 15”...
- Page 2 Natural Stone top works with most 37" wide, standard depth vanities Pre drilled faucet holes for an 8" widespread faucet Sinkcut out accomidates the YSA1092001 Bristol undermount ceramic sink 4” 4” 11” Side Back splash www.maykke.com SPECIFICATION SHEET REV. 12292015...
- Page 3 By IAPMO, ceramic lavatory warpage is defective only if warpage of flat slab out of horizontal plane exceeds 6.3 mm/m (0.25 in/ft) on all sizes OR warpage on back of lavatories that are attached to the wall exceeds 3 mm (0.13 in). www.maykke.com SPECIFICATION SHEET REV. 03112016...
- Page 4 Installation, Care Guide and Warranty Wall-Hung Vanity Set YSA1203601 YSA1203602...
-
Page 5: Pre-Installation
Observe all state and local building codes. PRE-INSTALLATION 由 Autodesk 教育版产品制作 Tools Required Phillips Rubber mallet Safety goggles screwdriver Silicone Level Compound Hardware Included Part Description Quantity Mounting Brackets 2 sets Anchor and screws 2 sets www.maykke.com INSTALLATION AND CARE GUIDE REV. 05092016... -
Page 6: Installation
These lines will help you spot where to place the screws in Step 3. □ Using a 5/16" drill 2 holes into the wall and secure the anchors into the wall. www.maykke.com INSTALLATION AND CARE GUIDE REV. 05092016... - Page 7 □ Position the wall vanity to the wall cleat on the wall and let it rest into the cleat Fig 4 由 Autodesk 教育版产品制作 Leveling vanity □ Verify the vanity is level and back rail is flush against the wall. www.maykke.com INSTALLATION AND CARE GUIDE REV. 05092016...
- Page 8 (D) on the top (C), pressing firmly together. □ Secure the sink (D) to the top (C) with the screws. Securing the vanity top (If installing Maykke vanity top) (see fig 5) □ Place the vanity top (C) with the sink (D) over the vanity (A).
- Page 9 By turning the screw clockwise or counter clockwise it will adjust the depth of the drawer. Adjust the drawer until the face is flush with the vanity frame. www.maykke.com INSTALLATION AND CARE GUIDE REV. 05092016...
-
Page 10: Care And Cleaning
Though non-porous, it is not stain, scratch, or heat proof. Spills should be cleaned as soon as possible. Cleaning: For best results use warm water with a small amount of non-abrasive cleaner that does not contain bleach. www.maykke.com INSTALLATION AND CARE GUIDE REV. 05092016... -
Page 11: Warranty
Imperfections such as small surface splits, small dark holes or darker mineral streaks are natural and are not considered defects. Contact support@maykke.com or call toll free 1 (877) 659-2858 M-F 7:30am - 4:30pm (PST) with any questions or warranty concerns www.maykke.com...
