WINSTON LINEN TOWER
LIMITED LIFETIME WARRANTY
WHAT IS COVERED
All products in the package carry a One-Year Limited Lifetime warranty. This warranty applies only to the original
purchaser and to the original installation of the product.
WHAT IS NOT COVERED
Damage caused during moving or during installation is not a defect or warranty issue and will not be considered as such.
This warranty does not cover product failure caused by abusive treatment, surface scratches, misuse, neglect or damage
due to handling or faulty installations. All wood naturally ages, darkens, changes in color, and mellows over time due
to exposure to light. While this color change is imperceptible from day to day
time, or due to amount of light the wood is exposed to. Imperfections such as small surface splits, small dark holes or
darker mineral streaks are natural and are not considered defects.
PRE-INSTALLATION
Tools Required
Rubber mallet
Hardware Included
AA
Part
Description
AA
Leg levelers (pre-installed on legs)
Materials Required
Description
Wood screws
5/16" Lag Bolts (min. 250lbs) load bearing
Washers for Lag Bolts
PRODUCT INSTALLATION
PRODUCT INSTALLATION
Safety goggles
Level
Quantity
Quantity
Silicone
Compound
4
2
1
2
2
1
MODEL: YSA1432101
Phillips
screwdriver
REV 111715
Advertisement
Table of Contents
Related Manuals for Maykke Winston
Summary of Contents for Maykke Winston
- Page 1 WINSTON LINEN TOWER PRODUCT INSTALLATION MODEL: YSA1432101 LIMITED LIFETIME WARRANTY WHAT IS COVERED All products in the package carry a One-Year Limited Lifetime warranty. This warranty applies only to the original purchaser and to the original installation of the product.
-
Page 2: Package Contents
WINSTON LINEN TOWER PRODUCT INSTALLATION PRE-INSTALLATION (continued) Package Contents Part Description Quantity Cabinet body INSTALLATION Tracing the outline of the vanity Determine the ideal location for your new bath furniture. If placing the side cabinet along the wall, then trace its outline on the wall. - Page 3 WINSTON LINEN TOWER PRODUCT INSTALLATION INSTALLATION (continued) Installing support for vanity properly support the vanity. To properly secure the vanity, the middle of the required 2x6 backing material must be 31-7/8” Extend the backing material beyond the width of the vanity to the nearest stud.
-
Page 4: Door Adjustment
WINSTON LINEN TOWER PRODUCT INSTALLATION DOOR ADJUSTMENT LEFT TO RIGHT If the gap between the door and vanity side panel needs adjustment, turn the screw closest to the door clockwise vanity side panel or counter clockwise. door Make sure to adjust both the top and bottom hinges to keep the door level. - Page 5 WINSTON LINEN TOWER PRODUCT INSTALLATION DRAWER ADJUSTMENT UP AND DOWN If the gaps above or below the drawer need adjustment, simply turn the screw that is mounted to the glide of the drawer box. By loosening the screws this gives the drawer box freedom to move up or down.
-
Page 6: Pre-Installation
WINSTON LINEN TOWER PRODUCT INSTALLATION MODEL: YSA1432101 PRE-INSTALLATION Tools Required Phillips Rubber mallet Safety goggles screwdriver Silicone Level Compound Hardware Included Part Description Quantity Wall cleat 1 set Anchor and screws 2 sets Materials Required Description Quantity 3/4" length wood screws... - Page 7 WINSTON LINEN TOWER PRODUCT INSTALLATION PRE-INSTALLATION (continued) Package Contents Part Description Quantity Cabinet body The linen cabinet may be placed on the wall as a standalone cabinet, or installed on top of the Woodbridge side cabinet. If installing on the wall please follow steps 1 - 3.
-
Page 8: Hanging The Cabinet
WINSTON LINEN TOWER PRODUCT INSTALLATION INSTALLATION (continued) Installing wall cleat to the cabinet Locate the pre-drilled holes behind the cabinet. Place the wall cleat over the back of the cabinet and line up the holes, then fasten the screws. Hanging the cabinet Lift and slowly drop the cabinet so the wall cleats meet and sit in place. - Page 9 WINSTON LINEN TOWER PRODUCT INSTALLATION INSTALLATION Placing linen cabinet over side cabinet Place the linen cabinet over the side cabinet making sure the corners line up. Use 3/4" length wood screws from inside of the linen cabinet to the top of the side cabinet.
-
Page 10: Care And Cleaning
WINSTON LINEN TOWER PRODUCT INSTALLATION CARE AND CLEANING WOOD DOORS AND PANELS Dust cabinets frequently with a soft, lint-free cloth. You may dampen the cloth with water or with a spray-type dust remover. Clean up spills immediately. Use a clean, damp cloth if necessary. Wipe dry with another clean soft cloth. Cloth is better than paper towels for this purpose.
