1. Wiring
※ Caution : When you are holding the handset while the hook switch is off and someone may push
the button of camera, you may lose your hearing because of high volume of calling sound.
2. Specification
Power Source
Mount Type
Wiring
Dimension(mm)
Distance
Warranty Period
Environment condition
Operating Temperature
Operating Humidity
Caution : To reduce the risk of electric shock, do not remove cover (or back).
no user-serviceable part inside refer servicing to qualified service personnel.
DC 24V (from TP-12RM)
Surface-mount type
2 wires
72(w) x 215(h) x 38(d)
1km
1 year
0 ~ 40℃
Less than 90%
Caution
Risk of electric shock Do Not
OPEN
