23" LCD Color Monitor
Service
Service
Service
Description

Table of Contents.........................................................1

Revision List................................................................2
Important Safety Notice...............................................3
1.Monitor Specification.................................................4
2.LCD Monitor Description.......................................6
3.Operation Instruction...............................................7
3.1.General Instructions.................................................7
3.2.Hot Keys......................................................7
3.3.OSD Setting.......................................................8
4.Input/Output Specification.......................................24
4.1.Input Signal Connector.........................................24
4.2.Factory Preset Display Modes...............................25
4.3.Panel Specification.............................................26
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
All manuals and user guides at all-guides.com
Table of Contents
Page
5.Block Diagram............................................29
6.Schematic.......................................................30
6.1.Main Board....................................................30
6.2.Key Board......................................................37
7.PCB Layout.....................................................38
7.1.Main Board....................................................38
7.2.Key Board....................................................40
8.Maintainability..................................................41
8.2.Trouble Shooting.........................................42
10.Monitor Exploded View.................................48
11.BOM List..................................................50
SAFETY NOTICE
Description
AOC E2357FH
Horizontal Frequency
30-83 KHz
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E2357FH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AOC E2357FH

Summary of Contents for AOC E2357FH

  • Page 1: Table Of Contents

    All manuals and user guides at all-guides.com 23" LCD Color Monitor AOC E2357FH Service Service Service Horizontal Frequency 30-83 KHz Table of Contents Description Page Description Page 5.Block Diagram……..…………....29 Table of Contents..……......……..1 6.Schematic……………........30 Revision List.…........…………..2 6.1.Main Board………...........30 Important Safety Notice.……......……..3 6.2.Key Board...……..........37...

  • Page 2: Revision List

    All manuals and user guides at all-guides.com Revision List Version Release Date Revision History L&T Model Name HDBJHH2CCSGHDNF.LF Jun-12-2012 Initial Release HDBJHH2JCS4ADNF.LF HDBJHH2MCS3ADNF.LF HDBJHH2CCSSCDNF.LF HDBJHH6LCSCADNF.LF HDBJHH6CCSGHDNF.LF HDBJHH6JCS4ADNF.LF HDBJHH6MCS3ADNF.LF HDBJHH6TCS1RDNF.LF JUL-08-2012 Add new model...

  • Page 3: Important Safety Notice

    All manuals and user guides at all-guides.com Important Safety Notice Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service procedures recommended by AOC and described in this service manual are effective methods of performing service operations.

  • Page 4: Monitor Specification

    All manuals and user guides at all-guides.com 1. Monitor Specifications...
  • Page 5 All manuals and user guides at all-guides.com...

  • Page 6: Lcd Monitor Description

    All manuals and user guides at all-guides.com 2. LCD Monitor Description The LCD MONITOR will contain a main board and a key board which house the flat panel control logic, brightness control logic and DDC. Monitor Block Diagram Flat Panel and LED Drive.

  • Page 7: General Instructions

    All manuals and user guides at all-guides.com 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control knobs are located at front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences. 3.2 Hotkeys Power Press the Power button to turn on/off the monitor.

  • Page 8: Osd Setting

    All manuals and user guides at all-guides.com 3.3 OSD Setting Basic and simple instruction on the control keys. 1) Press the MENU-button to activate the OSD window. 2) Press to navigate through the functions. Once the desired function is highlighted, press the <...
  • Page 9 All manuals and user guides at all-guides.com Luminance 1. Press (Menu) to display menu MENU 2. Press < or > to select (Luminance), and press to enter. MENU 3. Press < or > to select submenu, and press to enter. MENU...
  • Page 10 All manuals and user guides at all-guides.com 4. Press < or > to adjust. Press to exit. AUTO...
  • Page 11 All manuals and user guides at all-guides.com Image Setup 1. Press (Menu) to display menu. MENU 2. Press < or > to select (Image Setup) , and press MENU to enter. 3. Press < or > to select submenu, and press to enter.
  • Page 12 All manuals and user guides at all-guides.com 4. Press < or > to adjust. Press to exit. AUTO...
  • Page 13 All manuals and user guides at all-guides.com Color Setup 1. Press (Menu) to display menu. MENU 2. Press < or > Color to select Setup) , and press MENU to enter. 3. Press < or > to select submenu, and press to enter.
  • Page 14 All manuals and user guides at all-guides.com 4. Press < or > to adjust. Press to exit. AUTO Picture Boost...
  • Page 15 All manuals and user guides at all-guides.com 1. Press (Menu) to display menu. MENU 2. Press < or > (Picture Boost) to select , and press to enter. MENU 3. Press < or > to select submenu, and press to enter. MENU...
  • Page 16 All manuals and user guides at all-guides.com 4. Press < or > to adjust. Press to exit. AUTO...
  • Page 17 All manuals and user guides at all-guides.com OSD Setup 1. Press (Menu) to display menu. MENU 2. Press < or > (OSD Setup) to select , and press MENU to enter. 3. Press < or > to select submenu, and press to enter.
  • Page 18 All manuals and user guides at all-guides.com 4. Press < or > to adjust. Press to exit. AUTO...
  • Page 19 All manuals and user guides at all-guides.com Extra 1. Press (Menu) to display menu. MENU 2. Press < or > (Extra) to select , and press MENU to enter. 3. Press < or > to select submenu, and press to enter. MENU...
  • Page 20 All manuals and user guides at all-guides.com 4. Press < or > to adjust. Press to exit. AUTO...
  • Page 21 All manuals and user guides at all-guides.com Exit 1. Press (Menu) to display menu. MENU 2. Press < or > (Exit) to select , and press MENU to enter.

  • Page 22: Input/Output Specification

    All manuals and user guides at all-guides.com 4. Input/Output Specification 4.1 D-SUB CONNECTORS and DVI CONNECTORS Pin Assignments 15-Pin Side of the Signal Cable Pin Number Pin Number 15-Pin Side of the Signal Cable...
  • Page 23 All manuals and user guides at all-guides.com Video-Red Video-Green Ground N.C. Video-Blue N.C. DDC- Serial data Detect Cable sync GND-R sync GND-G DDC- Serial clock GND-B Pin Number Signal Name Pin Number Signal Name TMDS Data 2+ TMDS Clock Shield TMDS Data 2 Shield TMDS Clock TMDS Data 2...

  • Page 24: Factory Preset Display Modes

    All manuals and user guides at all-guides.com 4.2 Factory Preset Display Modes...

  • Page 25: Panel Specification

    All manuals and user guides at all-guides.com 4.3 Panel Specification 4.3.1 General Features LM230WF5-T2F2 is a Color Active Matrix Liquid Crystal Display with an integral Light Emitting Diode (LED) backlight system. The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in the normally white mode.
  • Page 26 All manuals and user guides at all-guides.com 4.3.3 Electrical Characteristics Values Parameter Symbol Unit Notes MODULE : Power Supply Input Voltage Permissive Power Input Ripple (60Hz) 1330 1730 LCD-MOSAIC Power Supply Input Current (60Hz) 1520 1980 LCD-BLACK (75Hz) 2480 LCD-BLACK Power Consumption 6.65 8.65...
  • Page 27 All manuals and user guides at all-guides.com 4.3.4 Optical Characteristics (Ta=25 °C, V =5.0V, f =60Hz, D =72MHz, Is=85mA) Values Parameter Symbol Units Notes Contrast Ratio 1000 (PR-880) Surface Luminance, white cd/m (PR-880)  Luminance Variation WHITE (PR-880) Rise Time Response Time (RD80S) Decay Time...

  • Page 28: Block Diagram

    All manuals and user guides at all-guides.com 5. Block Diagram 5.1 Main Board CRYSTAL Panel Interface 24.576MHz (CN301) (X401) Flash Memory Scalar IC HX6823-A EPAD-LQFP-128 Key Control Interface MX25L2026DM1I (Include ADC, OSD, MCU) (CN405) (U402) (U401) D-Sub Connector HDMI Connector HDMI Connector (CN101) (CN501)

  • Page 29: Schematic

    All manuals and user guides at all-guides.com 6. Schematic 6.1 Main Board 715G5240M0D000004L CN101 D-SUB 15P VGA_CABLE_DET VGA_CABLE_DET 5 VGA_5V DDC1_SCL DDCSCL_A DET_VGA R102 DDC1_SCL VSIN0 BIN0- FB102 HSIN0 BIN0 R103 C102 GIN0- BIN0 10R 1/16W 5% DDC1_SDA DDCSDA_A GIN0 R104 19 OHM 500mA DDC1_SDA...
  • Page 30 All manuals and user guides at all-guides.com CN501 HDMI SHDMI1/D2+ R502 0.05R RX2+ D2 Shield SHDMI1/D2- R503 0.05R RX2- SHDMI1/D1+ R504 0.05R RX1+ D1 Shield SHDMI1/D1- R505 0.05R RX1- SHDMI1/D0+ R506 0.05R RX0+ D0 Shield SHDMI1/D0- R507 0.05R RX0- SHDMI1/CK+ R508 0.05R RXC+...
  • Page 31 All manuals and user guides at all-guides.com PA[0..9] PB[0..9] PA[0..9] PB[0..9] LVA3P CN301 LVB3P LVA3M CONN LVB3M LVACKP LVB0M RXO0- LVBCKP LVACKM LVB0P RXO0+ LVBCKM LVA2P LVB1M RXO1- LVB2P LVA2M LVB1P RXO1+ LVB2M LVA1P LVB2M RXO2- LVB1P LVA1M LVB2P RXO2+ LVB1M LVA0P LVB0P...
  • Page 32 All manuals and user guides at all-guides.com R401 10R XTAL_OUT R402 10R XTAL_IN AVDD33_HDMI PVDD1_33 EARAVDD33 AVDD_PLL VCCK R403 1MOHM 1/16W +/-5% HVDD VCC3IO DACAVDD33 AVDD3V_LV X401 U401 24.576MHz C401 C402 20pF 20pF TSTMD X1 GROUNG TSTMD R486 NC/10K 1/16W 5% SHIELDING RST_N RST_N...
  • Page 33 All manuals and user guides at all-guides.com +5V_AUDIO +5V_AUDIO +5V_AUDIO 2,3,5,7 +5V_AUDIO 2,3,5,7 VCC1D2 U702 VCC3.3 G5725ADJT11U L702 U701 G5725ADJT11U L701 10uH C710 10uH R702 2U2 16V 100 OHM 1/10W R704 C708 R701 C709 51K 1% 2U2 16V 100 OHM 1/10W R703 10N 50V C703...
  • Page 34 All manuals and user guides at all-guides.com +5V_AUDIO APA2606NI PAM8007HNR R601 C630 0.47U 100K C631 0.47U CN601 R602 110R 1/10W 5% OUTL VCC3.3 R603 100R 1/16W 5% R622 0OHM R604 110R 1/10W 5% OUTR R627 0OHM PHONEJACK R605 10K 1/16W 5% R645 0OHM FB601...
  • Page 35 All manuals and user guides at all-guides.com +12V D801 L801 +12V 47UH R801 C801 C802 B3100B 0.1UF50V 150UF 25V C803 10 OHM 1/4W Q801 R802 0.47UF 50V R803 0 OHM 1/4W AOD482 R804 BKLT-EN C804 C807 R805 C805 160K 1% R806 300K C806...
  • Page 36 Auto MENU Power Differential T P V ( Top Victory Electronics Co . , Ltd. ) OEM MODEL AOC e943Fw Size 715G4164-K0C-000-0040_20100420.DSN TPV MODEL 絬 隔 瓜 絪 腹 e943Fw Key Component 2.0 Touch key PCB NAME 715G4164-K0C <称爹> 称 爹...

  • Page 37: Main Board

    All manuals and user guides at all-guides.com 7. PCB Layout 7.1 Main Board 715G5240M0D000004L...
  • Page 38 All manuals and user guides at all-guides.com...

  • Page 39: Key Board

    All manuals and user guides at all-guides.com 7.3 Key Board 715G4842K0E000004F...

  • Page 40: Maintainability

    All manuals and user guides at all-guides.com 8. Maintainability 8.1 Equipments and Tools Requirement Voltmeter. Oscilloscope. Pattern Generator. DDC Tool with an IBM Compatible Computer. Alignment Tool. LCD Color Analyzer. Service Manual. User Manual.

  • Page 41: Trouble Shooting

    All manuals and user guides at all-guides.com 8.2 Trouble Shooting No Power No power Check power cable is Re-plug the power cable tightened? Check Power “On/Off” Turn on the Power “On/Off” switch is “On”? Check the LED Check the AC power indicate is OK? Replace main board and check connections Replace key board and check connections...
  • Page 42 All manuals and user guides at all-guides.com 2. No Video (Power LED White) No Video (Power LED White) Press the power Replace the main board button is OK? Replace the main The end board and connection Check the LVDS/FFC Replace the LVDS/FFC cable or panel cable or panel Replace the key board...
  • Page 43 All manuals and user guides at all-guides.com 3. DIM DIM (image overlap, focus or flicker) Reset in factory mode The end Set to the optimal The end frequency, select the recommended frequency Readjust the phase and pixel The end clock in the user mode Pull out signal cable and Check the signal cable check “Self Test Feature...
  • Page 44 All manuals and user guides at all-guides.com 4. Color is not optimal Color is not optimal Color shift Miss color Reset the factory mode Replace the signal cable In the user mode, set the” color settings” until customer satisfy The end Pull out the signal cable and check the screen color display is normal?

  • Page 45: White-Balance, Luminance Adjustment

    All manuals and user guides at all-guides.com 9. White- Balance, Luminance Adjustment Approximately 30 minutes should be allowed for warm up before proceeding white balance adjustment. How to setting MEM channel you can reference to chroma 7120 user guide or simpl use “SC” key and “NEXT” Key to modify xyY value and use “ID”...
  • Page 46 All manuals and user guides at all-guides.com C. Adjust Cool (9300K) color-temperature 1. Switch the Chroma-7120 to RGB-Mode (with press “MODE” button) 2. Switch the MEM. Channel to Channel 9 (with up or down arrow on chroma 7120) 3. The LCD-indicator on chroma 7120 will show x = 283 ±30, y = 297 ±30 4.

  • Page 47: Monitor Exploded View

    All manuals and user guides at all-guides.com 10. Monitor Exploded View...
  • Page 48 All manuals and user guides at all-guides.com Description BEZEL Power lens Main Frame Hinge Hinge bracket Back cover Rubber foot Stand cover Stand INNR_F Stand INNR_P Part No. Description STAND CLIP D1G1030-8-120 SCREW M3X8 Spring M1G140-8-125 SCREW M4X8 Release Bin M1G330-6-125 SCREW M3X6 Release Bin Clip...

  • Page 49: Bom List

    0M1G-140--8125 SCREW 0M1G1730--8225-CR3 screw(Hinge) 0M1G3030--6-47-CR3 SCREW 0M1G3130--5-47-CR3 SCREW M3 x5 0Q1G-130--6120 SCREW (T3X6) 0Q1G-140--8120 SCREW T4X8 708GDF12-CP-2A AOC 40(1890) Q45G--77--4 PE FILM Q50G---4-10 TIE (Y1900221) Q52G---1185-98 3M TAPE 750GMT230W5F21N100 PANEL LM230WF5-T2F2 2436L-2472A LM230WF5-T2F2-831 0M1G3530--4120 M3*4,Nickel plating 3550S-1351A SECC,T=0.6mm ,LM230WF5-T2F2...
  • Page 50 All manuals and user guides at all-guides.com 10*5*2 6060L-2427A LM230WF5(TJF1,T2F2) 6061L-2009A LM230WF5-TJF1-831 0ILUL-0125A LS0608M2-C1TS, LUSEM, 720, 6, MIN LTEXNSSNEX5-02300T12, 525.1 X 6308L-3748A 300.2, LGC, T, E, X, N, S, S, N, E, X, 5, 02300, Top, 12 6308L-3749A LTBXNSSNEX5-02300B12, 512.2 X 289. Source, Single, None-C/SKD, 6871L-2701A LM230WF5-TJF1-831, Single Side...
  • Page 51 All manuals and user guides at all-guides.com 0DHZL-0065A SDZ5V1D, AUK, SOD-323, R/TP 0FSLO-0013A F0603HI3000V032T, AEM, Ceramic LDA5001A, LGD, LVDS, 6/8, 1/2, 0ILDL-0001A MINI-LVDS, 6, 1, DRD, GIP, AFRC, DGA, ODIN2, MLF, TR, 68 0IRTL-0022A RT9166A-33GX, RICHTEK, FIX_3.3V M24C04-RDW, STmicroeletronics, 4K, 0ISGL-0008C 5ms, TSSOP, R/TP, 8 0ISML-0002B...
  • Page 52 All manuals and user guides at all-guides.com R104,R202 0RH2402C422 24K OHM 1/16W 1608 1% D R/TP R126 0RH3001C422 3K OHM 1/16W 1608 1% D R/TP R120,R2 0RH3002C422 30K OHM 1/16W 1608 1% D R/TP R201 0RH3302C422 33K OHM 1/16W 1608 1% D R/TP R110 0RH3901C422 3.9K OHM 1/16W 1608 1% D R/TP...
  • Page 53 All manuals and user guides at all-guides.com TORAY, 188E60L, T=0.188, 3M, 1363-60, 3953L-0100K 126.2*1.6*0.188 , LM230WF5-T2F2 PMMA, Flat, 2.0, Printing, 5150L-0706A LM230WF5-T2F2 WR1,WOOREE LED, 56ea, White LED, 6916L-0902A LM230WF5-T2F2 5153L-0120A 05010HR-H10H , YRON-HO WRL LED,Top View,2ea(LED Chip Q'TY 6915L-0284B per PKG), 7020PKG, 6920L-0139A 523.9*4.6*1.2T,4EA,1L,56ea,AL 7250L-0864A...
  • Page 54 All manuals and user guides at all-guides.com C723,C801 067G315M1514KV EC 150UF 20% 25V 8*7 C301,C615,C616 067G315M2213HV EC 220UF 20% 16V 6.3*7 EC 220uF 20% 16V 6.3*7 3000 Hr KUAN 067G315M2213GV 2nd SOURCE C804 067G415Y330-9L EC 33UF 20% 100V 8*12 EC 33uF -20% 100V ED 8*12mm 067G415Y330-9K 2nd SOURCE 4000Hr CHINSAN...
  • Page 55 All manuals and user guides at all-guides.com IC ESD AZ1045-04F.R7G DFN2510P10E 056G-662-18 2nd SOURCE Amazing U102,U103,U501,U5 IC ESD PROTECT AZC398-04S.R7G 056G-662-52 SOT23-6 Amazing IC ESD PROTECT AZC399-04S 056G-662-48 2nd SOURCE SOT23-6L AMAZING NO-SUGGEST IC ESD PROTECT 056G-662-49 2nd SOURCE L30ESDL5V0C6-4 SOT23-6L LITEON 056G-662505 IC ESD AOZ8105CI SOT-23-6 AOS 2nd SOURCE...
  • Page 56 All manuals and user guides at all-guides.com R103,R109,R115,R4 RST CHIPR 10 OHM +-5% 1/16W 0402 061G0402100-JT 01,R402,R515,R536 TZAI YUAN RST CHIPR 10 OHM -5% 1/16W 0402 061G0402100-JY 2nd SOURCE YAGEO RST CHIPR 10 OHM -5% 1/16W 0402 061G0402100-JF 2nd SOURCE FENGHUA R119,R120,R416,R4 20,R424,R441,R443,...
  • Page 57 All manuals and user guides at all-guides.com RST CHIPR 11.5 KOHM -1% 1/16W 061G04021152FY 2nd SOURCE 0402 YAGEO RST CHIPR 12 KOHM +-1% 1/16W 0402 R646 061G04021202FT TZAI YUAN RST CHIPR 12 KOHM -1% 1/16W 0402 061G04021202FY 2nd SOURCE YAGEO RST CHIPR 15 KOHM +-5% 1/16W 0402 R465,R466 061G0402153-JT...
  • Page 58 All manuals and user guides at all-guides.com YAGEO RST CHIPR 30 KOHM -5% 1/16W 0402 061G0402303-JT 2nd SOURCE TZAI YUAN RST CHIPR 33 KOHM +-5% 1/16W 0402 R613,R636,R711 061G0402333-JF FENGHUA RST CHIPR 33 KOHM -5% 1/16W 0402 061G0402333-JY 2nd SOURCE YAGEO RST CHIPR 390 OHM +-5% 1/16W 0402 R404...
  • Page 59 All manuals and user guides at all-guides.com RST CHIPR 7.5 KOHM -5% 1/16W 0402 061G0402752-JT 2nd SOURCE TZAI YUAN R415 061G0603000-JF RST CHIPR MAX 0R05 1/10W FENGHUA 061G0603000-JY RST CHIPR MAX0R05 1/10W YAGEO 2nd SOURCE RST CHIP MAX 0R05 1/10W TZAI R118 061G0603000-JT YUAN...
  • Page 60 All manuals and user guides at all-guides.com RST CHIPR 160 KOHM -1% 1/10W 061G06031603FY 2nd SOURCE 0603 YAGEO RST CHIPR 160 KOHM -1% 1/10W 061G06031603FI 2nd SOURCE 0603 TA-I RST CHIPR 200 OHM +-5% 1/10W 0603 R413 061G0603201-JF FENGHUA RST CHIPR 200 OHM -5% 1/10W 0603 061G0603201-JY 2nd SOURCE YAGEO...
  • Page 61 All manuals and user guides at all-guides.com 061G1206000-JY RST CHIPR MAX0R05 1/4W YAGEO 2nd SOURCE CHIPR 1206 10 OHM +-5% 1/4W R801 061G1206100-JF FENGHUA RST CHIPR 10 OHM -5% 1/4W 1206 061G1206100-JY 2nd SOURCE YAGEO RST CHIPR 10 OHM -5% 1/4W TZAI 061G1206100-JT 2nd SOURCE YUAN...
  • Page 62 All manuals and user guides at all-guides.com MLCC 0402 1uF -10% 10V X5R 065G0402105A5K---A 2nd SOURCE SAMSUNG NO-SUGGEST MLCC 0402 1uF -10% 065G0402105A5K---3 2nd SOURCE 10V X5R TDK C116,C117,C635,C7 MLCC 0402 22pF +-5% 50V NPO 065G040222031J---A SAMSUNG MLCC 0402 22pF -5% 50V NPO TAIYO 065G040222031J---T 2nd SOURCE YUDEN...
  • Page 63 All manuals and user guides at all-guides.com X7R TDK MLCC 0402 47nF -10% 16V X7R TAIYO 065G040247312K---T 2nd SOURCE YUDEN MLCC 0402 5pF +-0.25pF 50V NPO C103,C108,C112 065G040250931C---Y YAGEO MLCC 0402 5pF -0.25pF 50V NPO 065G040250931C---A 2nd SOURCE SAMSUNG MLCC 0402 6.8nF +-10% 50V X7R C604,C605 065G040268232K---Y YAGEO...
  • Page 64 All manuals and user guides at all-guides.com NO-SUGGEST MLCC 0603 10uF -20% 065G060310605M---3 2nd SOURCE 6.3V X5R TDK MLCC 0603 0.22uF +-10% 25V X7R C812 065G060322422K---T TAIYO YUDEN NO-SUGGEST MLCC 0603 0.22uF 065G060322422K---3 2nd SOURCE -10% 25V X7R TDK MLCC 0603 0.22uF -10% 25V X7R 065G060322422K---A 2nd SOURCE SAMSUNG...
  • Page 65 All manuals and user guides at all-guides.com MLCC 0805 0.47uF -10% 50V X7R 065G080547432K---T 2nd SOURCE TAIYO YUDEN NO-SUGGEST MLCC 0805 0.47uF 065G080547432K---3 2nd SOURCE -10% 50V X7R TDK MLCC 1206 10uF +-10% 25V X5R C620,C636,C713 065G120610625K---A SAMSUNG NO-SUGGEST MLCC 1206 10uF -10% 065G120610625K---3 2nd SOURCE 25V X5R TDK...
  • Page 66 35mm X 18mm X5.5mm F19G0001--1 SPRING F20G0001--1 STAND BASE F20G3001011 diecasting F40G000361536A E2357FH POP Label ID LABEL for D2357PH_E2357FH Fire F40G230W615-1A bird F44GDA12615-1A Carton for E2357FH AP F44GDF12102 F44GDF12202 F52G10012Z0001 529mm*40mm) F52G1201163001 double sides adhesive tape F52G1801MNT002 Mylar F52G2001001 50mm*30mm)
  • Page 67 All manuals and user guides at all-guides.com F70G23C1615-7B E2357FH CD MANUAL SPEAKER 4 OHM 2.5W 62*20 270+90 CN603 F78G025A--6-2V Vanson FFC CABLE 10PIN 178MM P0.5MM E09502 F95G176X-10304 WENXIN F95G176J-10304 FFC CABLE 10PIN 180mm 0.5MM KOTL 2nd SOURCE F95G176T-10304 FFC CABLE 10PIN 180mm 0.5MM DIY 2nd SOURCE FFC CABLE 30PIN 327mm 1.0MM...
  • Page 68 All manuals and user guides at all-guides.com C003,C004 065G040212031J---Y MLCC 0402 12pF +-5% 50V NPO YAGEO MLCC 0402 12pF -5% 50V NPO 065G040212031J---A 2nd SOURCE SAMSUNG CHIP LED blue/Orange D001 081G15BY--2-GP GPTD12048BOC1-A GUANGPU LED Blue/Orange 12-22/BHS2C-C30/2C 081G15BY--2-EL 2nd SOURCE EVERHIGHT DIODE ZD LUDZS5.6BT1G 5.6V/0.5W ZD001,ZD002 093G-39S501--T...
