AOC e2350Sh Service Manual
Hide thumbs Also See for e2350Sh:

Advertisement

23" LCD Monitor
Service
Service
Service
Table of Contents....................................................1
Revision List...................................................................2
Important Safety Notice.................................................3
1.Monitor Specification...................................................4
2.LCD Monitor Description.........................................5
3.Operation Instruction.................................................6
3.1.General Instructions..................................................6
3.2.Control Buttons and Connections...............................6
3.3.OSD Setting............................................................8
4.Input/Output Specification........................................24
4.1.Input Signal Connector..........................................24
4.2.Preset Display Modes................................25
4.3.Panel Specification...........................................26
5.Block Diagram............................................................29
5.1.Main Board....................................................29
5.2.Power Board..................................................30
6.Schematic..........................................................31
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

Table of Contents

Page Description
6.Schematic..........................................................31
6.1.Main Board.......................................................31
6.2.Power Board....................................................36
7.PCB Layout.........................................................38
7.1.Main Board......................................................38
7.2.Power Board.....................................................40
7.3.Key Board........................................................42
8.Maintainability.....................................................43
8.2.Trouble Shooting.............................................44
10.Mechanical Instructions ............... ..............50
11.Monitor Exploded View......................................58
12.BOM List......................................................59
SAFETY NOTICE
1
AOC e2350Sh
Horizontal Frequency
30 - 83kHz
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e2350Sh and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AOC e2350Sh

  • Page 1: Table Of Contents

    23" LCD Monitor AOC e2350Sh Service Service Service Horizontal Frequency 30 - 83kHz Table of Contents Description Page Description Page Table of Contents…………………..…………………..…...1 6.Schematic…………..….........31 Revision List.…...........……..2 6.1.Main Board..…….…...........31 Important Safety Notice.….…......……..3 6.2.Power Board..……….........36 1.Monitor Specification......………....4 7.PCB Layout..………..........38 2.LCD Monitor Description……….……………………..5 7.1.Main Board………..…........38...
  • Page 2: Revision List

    Revision List Version Release Date Revision History TPV Model Name HDBGNZ6EAGA1DNE HDBSNZ6EAGA1DNE Initial release Aug.-11-2011 HDBGNZ6FAGA1DNE HDBGNZ6JAGA1DNE HDBSNZ6FAGA1DNE HDBSNZ6JAGA1DNE Dec.-07-2011 Add new models HDBGNZ6BAGA1DNE HDBSNZ6BAGA1DNE...
  • Page 3: Important Safety Notice

    Important Safety Notice Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service procedures recommended by AOC and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. The special tools should be used when and as recommended.
  • Page 4: Monitor Specification

    1.Monitor Specifications...
  • Page 5: Lcd Monitor Description

    2.LCD Monitor Description The LCD monitor will contain a main board, an adapter board, a converter board and a key board which house the flat panel control logic, brightness control logic and DDC. The power part will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage.
  • Page 6: Operation Instruction

    3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control knobs are located at front panel of the monitor (See Figure ). By changing these settings, the picture can be adjusted to your personal preferences. * The power cord should be connected.
  • Page 7 1. Power 2. Analog (DB-15 VGA cable) 3 DVI 4 HDMI 5. Audio To protect equipment, always turn off the PC and LCD monitor before connecting. 1 Connect the power cable to the AC port on the back of the monitor. 2 Connect one end of the 15-pin D-Sub cable to the back of the monitor and connect the other end to the computer's D-Sub port.
  • Page 8: Osd Setting

    3.3 OSD Setting Basic and simple instruction on the control keys. 1) Press the MENU-button to activate the OSD window. 2) Press - or + to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate it. press - or + to navigate through the sub-menu functions. Once the desired function is highlighted, press MENU-button to activate it.
  • Page 9 Luminance Press (Menu) to display menu. Press to select (Luminance), and press to enter. Press to select submenu, and press to enter. Press to adjust.
  • Page 10 Press two times to exit.
  • Page 11 Image Setup Press (Menu) to display menu. Press to select (Image Setup), and press to enter. Press to select submenu, and press to enter. Press to adjust.
  • Page 12 Press two times to exit.
  • Page 13 Color Setup Press (Menu) to display menu. Press to select (Color Setup), and press to enter. Press to select submenu, and press to enter. Press to adjust.
  • Page 14 Press two times to exit.
  • Page 15: Picture Boost

    Picture Boost Press (Menu) to display menu. Press to select (Picture Boost), and press to enter. Press to select submenu, and press to enter. Press to adjust.
  • Page 16 Press two times to exit.
  • Page 17 OSD Setup Press (Menu) to display menu. Press to select (OSD Setup), and press to enter. Press to select submenu, and press to enter. Press to adjust.
  • Page 18 Press two times to exit.
  • Page 19 Extra Press (Menu) to display menu. Press to select (Extra), and press to enter. Press to select submenu, and press to enter. Press to adjust.
  • Page 20 Press two times to exit.
  • Page 21 Exit Press (Menu) to display menu. Press to select (Exit), and press to enter. Press two times to exit Exit Exit the main OSD...
  • Page 22: Led Indicators

    Orange or red e-Saver Welcome to use AOC e-Saver monitor power management software! The AOC e-Saver features Smart Shutdown functions for your monitors, allows your monitor to timely shutdown when PC unit is at any status (On, Off, Sleep or Screen Saver);...
  • Page 23 Screen+ Welcome to "Screen+" software by AOC, Screen+ software is a desktop screen splitting tool, it splits the desktop into different panes, each pane displays a different window. You only need to drag the window to a corresponding pane, when you want to access it.
  • Page 24: Input/Output Specification

    4. Input/Output Specification 4.1 Input Signal Connector Analog connector...
  • Page 25: Preset Display Modes

    4.2 Preset Display Modes...
  • Page 26: Panel Specification

    4.3 Panel Specification 4.3.1 General Features LM230WF5-TLD1 is a Color Active Matrix Liquid Crystal Display Light Emitting Diode ( White LED) backlight system without LED driver. The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating in the normally white mode.
  • Page 27 LED array electrical characteristics LED driver design guide: The design of the LED driver must have specifications for the LED in LCD Assembly. The performance of the LED in LCM, for example life time or brightness, is extremely influenced by the characteristics of the LED driver.
  • Page 28 4.3.4 Optical Characteristics 25°C =120mA =5.0V, f =60Hz =119MHz,...
  • Page 29: Block Diagram

    5. Block Diagram 5.1 Main Board 04.SCALER 02.INPUT VCC3.3 SOG_DET SOG_DET VCC1.8 05.PANEL INTERFACE EDID_WP AHS0 AHS0 AVS0 AVS0 AVS0 PA[0..9] DDCSDA1 DDCSDA1 DDCSDA1 PA[0..9] PA[0..9] DDCSCL1 DDCSCL1 DDCSCL1 VGA_CABLE_DET VGA_CABLE_DET VGA_CABLE_DET PB[0..9] 02.D-SUB INPUT PB[0..9] PB[0..9] EDID_WP EDID_WP P_SCL P_SCL VLCD P_SDA...
  • Page 30: Power Board

    5.2 Power Board AC input Transformer Rectifier Bridge 14.5 EMI filter (T901) diodes Rectifier and Filter Start Resistor (R908,R911) Feedback PWM Control Circuit Power Switch LD7576AGR (Q901) (U901) Photo coupler Regulator (U902) (IC903) L801 D801 14.5V C809 MOSFET (Q806) (CN805) PWM Control ON/OFF MP3389EF...
  • Page 31: Schematic

    6. Schematic 6.1 Main Board 715G4641M01000004S CN101 RED+ D-SUB 15P FB101 BEAD R102 100R 1/16W 5% C102 47nF 16V RED- GREEN+ FB102 BEAD R103 100R 1/16W 5% C103 47nF 16V GREEN- BLUE+ FB103 BEAD R104 100R 1/16W 5% C104 47nF 16V BLUE- VGA5V R110...
  • Page 32 CN501 HDMI HDMI1/D2+ HDMI1_D2+ D2 Shield HDMI1/D2- HDMI1_D2- HDMI1/D1+ HDMI1_D1+ D1 Shield HDMI1/D1- HDMI1_D1- HDMI1/D0+ HDMI1_D0+ D0 Shield HDMI1/D0- HDMI1_D0- HDMI1/CK+ HDMI1_CK+ DET_HDMI CK Shield HDMI1/CK- HDMI1_CK- R753 CEC3* CEC_CTRL CE Remote HDMI_SCL DDC CLK HDMI_SDA DDC DATA R153 ZD104 HDMI1_+5V 1K 1/16W 5% NC/RLZ5.6B...
  • Page 33 VCC3.3 DVDD FB401 FB402 DVI_VCC +5V_SB VCC3.3 120 OHM 120 OHM C405 C407 C409 C410 100N16V 100N16V 100N16V 100N16V VCC3.3 MPLL_VDD +5V_SB AUDIO_VDD ADC_VDD CVDD DVDD C403 C402 DVI_VCC ADC_1V8 MVDD MVDD 10uF 16V 10uF 16V C404 C406 100N16V 100N16V FB403 FB404 ADC_VDD...
  • Page 34 PA[0..9] PB[0..9] PA[0..9] PB[0..9] LVB0M CN408 LVA0M LVB0P CONN LVA0P LVB1M LVB0M RXO0- LVA1M LVB1P LVB0P RXO0+ LVA1P LVB2M LVB1M RXO1- LVA2M LVB2P LVB1P RXO1+ LVA2P LVBCKM LVB2M RXO2- LVACKM LVBCKP LVB2P RXO2+ LVACKP LVB3M LVA3M LVB3P LVBCKM RXOC- LVA3P LVBCKP RXOC+ LVB3M...
  • Page 35 +5V_SB VCC3.3 U701 +5V_SB VCC3.3 VCC3.3 VOUT +5V_SB C702 R701 C701 10K 1/16W 5% 220uF/16V 100N16V C705 C703 C704 100N16V 100uF/16V 100N16V CN701 PWMB* R702 1K 1/16W 5% Adj_BACKLIGHT VCC3.3 U702 VCC3.3 NC/AP2114D-3.3TRG1 R704 VOUT 47K 1/16W 5% R705 ON/OFF 47K 1/16W 5% VCC3.3 +5V_SB...
  • Page 36: Power Board

    6.2 Power Board Adapter 715G4744P01000001C R929 100 OHM 1/4W BD901 C916 C928 F801 KBP208G R930 100 OHM 1/4W 2N2 500V 2N2 500V 0R05 1/4W +14.5V R903 100 OHM 1/4W R904 ZD901 250OHM2W MTZJ T-72 16B 80GL22T-3 C918 NC/470UF/25V T901 D901 POWER X'FMR SR515 R905...
  • Page 37 Converter 715G4013P01002004S +12V D801 F801 L801 0R05 4A 1/4W 33uH C810 C809 0.47uF 50V 100uF 50V SK310B ON/OFF U801 C803 0.22uf 50V MP3389EF Q806 C807 Q801 CN801 VFAULT 4.7UF 100V Gate APM8005 R801 R805 GATE 300KOHM 1/10W COMP PGND C801 470N 25V C804 ISENSE 10 OHM 1% 1/4W...
  • Page 38: Pcb Layout

    7. PCB Layout 7.1 Main Board 715G4641M01000004S...
  • Page 40: Power Board

    7.2 Power Board Adapter 715G4744P01000001C...
  • Page 41 Converter 715G4013P01002004S...
  • Page 42: Key Board

    7.3 Key Board 715G4747K0E000001C...
  • Page 43: Maintainability

    8. Maintainability 8.1 Equipments and Tools Requirement Voltmeter. Oscilloscope. Pattern Generator. DDC Tool with an IBM Compatible Computer. Alignment Tool. LCD Color Analyzer. Service Manual. User Manual.
  • Page 44: Trouble Shooting

    8.2 Trouble Shooting 1. No Power No power Check power cable is Re-plug the power cable tightened? Check Power “On/Off” Turn on the Power “On/Off” switch is “On”? Check the LED Check the AC power indicate is OK? Replace the converter board Replace main board and check connections Replace key board and check connections...
  • Page 45 2. No Video (Power LED Blue) No Video (Power LED Blue) Press the power Replace the main board button is OK? Replace the converter The end board Replace the main The end board and connection Replace the LVDS/FFC Check the LVDS/FFC cable or panel cable or panel Replace the key board...
  • Page 46 3. DIM DIM (image overlap, focus or flicker) Reset in factory mode The end Set to the optimal The end frequency, select the recommended frequency Readjust the phase and pixel The end clock in the user mode Pull out signal cable and Check the signal cable check “Self Test Feature and the PC...
  • Page 47 4. Color is not optimal Color is not optimal Color shift Miss color Reset the factory mode Replace the signal cable In the user mode, set the” color settings” until customer satisfy The end Pull out the signal cable and check the screen color display is normal? Replace the signal cable or PC Replace the main board...
  • Page 48: White-Balance,Luminance Adjustment

    9.White- Balance, Luminance Adjustment Approximately 30 minutes should be allowed for warm up before proceeding white balance adjustment. How to setting MEM channel you can reference to chroma 7120 user guide or simple use “SC” key and “NEXT” Key to modify xyY value and use “ID” key to modify the TEXT description Following is the procedure to do white-balance adjust .
  • Page 49 C. Adjust Cool (9300K) color-temperature 1. Switch the Chroma-7120 to RGB-Mode (with press “MODE” button) 2. Switch the MEM. Channel to Channel 9 (with up or down arrow on chroma 7120) 3. The LCD-indicator on chroma 7120 will show x=283±30,y=297±30 4.
  • Page 50: Mechanical Instructions

    10.Mechanical Instructions 1. Put the monitor on the EPE pad. 2. Lay down the monitor and the bottom side faces to Yourself.
  • Page 51 3. Pinch the hook and remove the base. 4. Use fixture to leave off the stand.
  • Page 52 5. Use fixture to remove the hinge cover. 6. Remove the screws of the stand.
  • Page 53 7. Remove the screws of the back cover. 8. Overturn the monitor and the top towards to yourself, and then take apart the front frame with hands.
  • Page 54 9. Prize up the front frame use fixture. 10. Overturn the monitor and take off the back cover.
  • Page 55 11. According to the different defective area to take off the KEPC, light line, LVDS, Hexagon screws, CBPC or PWPC to repair. (1)Remove the KEPC. (2)Pull the light line out.
  • Page 56 (3)Remove the Hexagon screws. (4)Remove the LVDS.
  • Page 57 (5)Overturn the iron plate and remove the screws, PWPC and CBPC.
  • Page 58: Monitor Exploded View

    11. Monitor Exploded Views...
  • Page 59: Bom List

    EPS-2350 H44GD014201 EPS-2350 H44GD014615 4A e2350Sh CARTON H45G 87 1 25 EPE COVER H52G1801 16006 insulating sheet H70G23C1615 3B e2350Sh CD MANUAL KEPCBHA5 KEY BOARD Q33G0504ABJ 1B0100 STAND TOP-2350 Q33G0505ABJ 1L0100 HINGE COVER-2350 Q34G7393AEDN1B0130 BEZEL Q34G7394ABJ 5B0100 REAR COVER 2350...
  • Page 60 089G404A15N IS AC POWER CORD 1500 2nd source H26G 800504 2B barcode H40G 18N61567A N950WA 印尼 ID label H40G000261526A e2350sh INA CARTON LABEL H41G1800615 1B 印尼 manual H41G780061583A 印尼 warranty card 808GE2350SHPHI E2350SH Philippines ASS'Y 089G 173 56 4B AUDIO CABLE...
  • Page 61 H40G 23N615 1A e2350Sd TW ID LABEL H40G 58261572A AOC TW WARRANTY LABEL H40G000261525A e2350sh TW CARTON LABEL H41G780961540A TW WARRANTY BOOKLIST 808GE2350SHUAE E2350SH United Arab Emirates ASS'Y 089G 173 56 4B AUDIO CABLE E08908 089G 184CAA500 HDMI CABLE 1800mm 2nd source...
  • Page 62 2nd source H40G 001624 2A CARTON LABEL BARCODE 2 H40G 24N61542A e2350Sd e2450Swd PRC ID LABEL H41G780961529A AP WARRANTY booklist 808GE2350SHVIE E2350SH Viet Nam ASS'Y 089G 173 56 4B AUDIO CABLE E08908 089G 184CAA500 HDMI CABLE 1800mm 2nd source E08908 089G 184GAA500 HDMI CABLE 1.8m...
  • Page 63 CN604 033G3802 4B Y CONNECTOR 4P 2.0 CN404 033G3802 6B Y WAFER CN701 033G3802 9B Y CONN 2.0 9P CN408 033G801930F CH FFC CONN 1.0mm 30P R/A 34mm 6mm R710 061G152M47964B SY RST MOF 4R7 5% 2W RSS02J4R70C150NH C711 067G315M1013HV 105 度...
  • Page 64 R140 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN R139 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN R138 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN R137 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN R136 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN...
  • Page 65 R157 061G0402223 JT RST CHIP 22K 1/16W 5% TZAI YUAN R134 061G0402223 JT RST CHIP 22K 1/16W 5% TZAI YUAN R124 061G0402223 JT RST CHIP 22K 1/16W 5% TZAI YUAN R612 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN R611 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN...
  • Page 66 C708 065G040210412K CAP 0402 100NF 10% 16V X7R C712 065G040210412K CAP 0402 100NF 10% 16V X7R C714 065G040210412K CAP 0402 100NF 10% 16V X7R C750 065G040210412K CAP 0402 100NF 10% 16V X7R C420 065G040210412K CAP 0402 100NF 10% 16V X7R C101 065G040210412K CAP 0402 100NF 10% 16V X7R...
  • Page 67 C106 065G040250931C CAP 0402 5PF 0.25pF 50V NP0 C105 065G040250931C CAP 0402 5PF 0.25pF 50V NP0 C610 065G060322422K CAP 0603 220N 25V X7R 10% C622 065G060322422K CAP 0603 220N 25V X7R 10% C624 065G080510615K CHIP 10uF 16V X5R 0805 C613 065G080510615K CHIP 10uF 16V X5R 0805 C475...
  • Page 68 090G6084 1 HEAT SINK D906 093G 60507 SCHOTTKY SRF1060 C0 10A 60V ITO-220AB 0M1G 930 8120 SCREW 3x8 055G 23524 WELDING FLUX WITHOUT PB Q51G 6 4509 GLUE_RTV Q55G 100625 TIN STICK_LOW ARGENTUM U901 056G 379529 AC/DC CONVERTER IC LD7576AGR SOP-7 RJ801 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA...
  • Page 69 D903 093G 6026T52T CTIFIER DIODE FR107 CN901 006G 31500 EYELET IC903 056G 158 10 T LDO IC AZ431AZ-AE1 TO-92 150MA 40V TO-92 Q904 057G 530503 T 2SD1207T R915 061G 17222052T TZ RST CFR 22R 5% 1/4W R906 061G152M10452T SY RST MOFR 100KOHM +-5% 2WS FUTABA R904 061G152M25152T SY RST MOF 250R 5% 2W...
  • Page 70 R853 061G0805000 JT RST 0805 0.05R MAX 1/8W R834 061G0805109 JT RST CHIP 1R 1/8W 5% TZAI YUAN R832 061G0805109 JT RST CHIP 1R 1/8W 5% TZAI YUAN R805 061G0805304 JF RST CHIPR 300KOHM +-5% 1/8W FENGHUA R818 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA F801 061G12060004JF...
