Grange RGTBR Assembly Instructions

RGTBR (A5 label & assembly) 12/1/18
ASSEMBLY INSTRUCTIONS
ROUND GARDEN TABLE WITH BACKRESTS
A
B
D E
G
H
F

BEFORE YOU START

•
Please ensure that you check all the
component parts for quantity and quality
before you commence building the product.
Report any missing parts immediately. The
manufacturer will not accept any responsibility
for damaged items once any part of the
product has been fitted or altered in any way.
•
Timber is a natural material and will react to
varying levels of moisture content - ie. will
swell or shrink. All of the Timber components
are pressure treated green.
However, should extra protection be required,
they should be treated using a wood
preservative treatment, following the
manufacturers instructions.

HEALTH AND SAFETY

DO ensure there is adequate working space
In order to reduce the risk of suffocation
please keep all plastic bags and small parts
away from children.
•
When you are ready to start, make sure you
have the right tools to hand, plenty of space
and a clean, dry area for assembly.
11:34 Page 1

PARTS LIST

A
Base Supports [lower] x 2
C
B
Base Supports [upper] x 2
C
Base Table Supports x 4
D
Bench Seats
E
Seat Backrests [sets] x 4
F
Round Table Top
G
Seat Support Strut
H
Seat Support [front] x 8
J
J
Seat Support [back] x 8

HARDWARE

u
5x50 screws
v
5x70 screws
w
M8 Nut
x
M8 Washer
y
M8x120
z
M8x120

AREA REQUIRED FOR ASSEMBLED STRUCTURE

x 4
x 1
x 8
x32
x16
x40
x40
x22
x18
dia.
243cm
©2018 Grange Fencing Ltd All rights reserved.
In line with the Company's policy of
continuous product development, the right
is reserved to change and improve product
design without prior notice.
All products and related emblems featured are
trademarks of Grange Fencing Ltd.
www.grangefen.co.uk
ROUND GARDEN TABLE
WITH BACKRESTS
RGTBR - 71.2cm [H - table] / 44cm [H - bench] x 243cm [dia.]
Self-Assembly required
PLAN
table dia. 118cm
bench
28cm
bench width 114cm
bench height 44cm
Home Delivery available
dia. 243cm
table
height
71.2cm
