Grange MONTEBELLO Assembly Instructions

Arbour

Hide thumbs Also See for MONTEBELLO:

The Montebello Arbour is made of planed pressure treated and FSC certified timber

and as such is guaranteed against rot for a minimum of 15 years. However, it must

be remembered that as a natural product, timber is subject to movement and weath-

ering as it seasons. It is not uncommon for small spits to occur when drying and

warping when timber is allowed to dry too rapidly. These will normally go back

when humidity rises, it is nature at work and not considered a fault.

Its colour will also change with time, a re-treatment, as required with a proprietary

wood treatment is recommended.

MONTEBELLO

ARBOUR

INSTRUCTIONS

SIDE SECTIONS

SEAT BACK

SEAT

BACK TRELLIS

CURVED ROOF

BEAMS

ROOF STRUTS

FINIAL

SUPPORT

STRUTS

Screw

3. 5 x 35 mm

Screw

3. 5 x 50 mm

Screw

3. 5 x 70 mm

Screw

4 x 60 mm

Table of Contents

Need help?

Do you have a question about the MONTEBELLO and is the answer not in the manual?

Page 1 Screw 3. 5 x 35 mm CARE OF YOUR ARBOUR The Montebello Arbour is made of planed pressure treated and FSC certified timber Screw 3. 5 x 50 mm and as such is guaranteed against rot for a minimum of 15 years. However, it must...
Page 2 Tools required (NOT SUPPLIED) Power screwdriver with Pozidrive No.2 bit. Tape measure. Take two of the curved sections 3mm pilot drill Hammer. for the roof. The curves have location Before you start. slots for the roof struts as Fig 5. Check the packs and make sure that you have all of the parts listed above.
