- Page 1 All manuals and user guides at all-guides.com INSTALLATION GUIDE Pro Ventilation Hood Liners...
-
Page 2: Table Of Contents
Contents Important Note Wolf Pro Ventilation Hood Liners ....3 To ensure the safe and efficient use of Wolf equipment, please take note of the following types of highlighted Safety Instructions . -
Page 3: Wolf Pro Ventilation Hood Liners
Pro Hood Liner Installation IMPORTANT NOTE: This installation must be completed Wolf Pro Hood Liner by a qualified installer or Wolf factory certified service. Model Number Read this entire installation guide prior to installation and Serial Number save for the local inspector’s reference. The homeowner should keep this installation guide for future reference. -
Page 4: Safety Instructions
• weight of the pro ventilation hood liner. Install the pro ventilation hood liner only with a • blower manufactured by Wolf. When cutting or drilling into wall or ceiling, do not • damage electrical wiring and other hidden utilities. -
Page 5: Installation Considerations
Product failure due to improper installation is not the hood does not have to match the height of the liner. covered under the Wolf warranty. Refer to the Wolf pro Interior dimensions of the decorative hood must exceed ventilation hoods use & care guide for warranty details, exterior dimensions of the liner. -
Page 6: Pro Hood Liner Specifications
All manuals and user guides at all-guides.com Pro Hood Liner Specifications Overall Dimensions PRO HOOD LINERS 6" WIDTH MINUS (152) " (35) 3" " 3" 12" (76) (578) (76) (305) 12" (305) 4" (102) " , 40 " , 46 "... - Page 7 Installation Specifications Electrical Requirements The illustration and chart below provides dimensions Wolf pro ventilation hood liners require a separate, critical for proper installation of the pro ventilation hood grounded 120 V AC, 60 Hz power supply. The service liner. Dimension A in the illustration will vary with the width should have its own 15 amp circuit breaker.
-
Page 8: Pro Hood Liner Installation
Install Ductwork PRO HOOD LINERS To reduce the risk of fire, use only metal ductwork. IMPORTANT NOTE: Pro ventilation hood liners must exhaust to the outdoors. Wolf recommends that the ventilation hood be installed DUCTWORK INSTALLATION THROUGH ROOF 30" to 36"... - Page 9 All manuals and user guides at all-guides.com Pro Hood Liner Installation wolfappliance.com/specs Wall Framing Hood Liner Preparation 1) Layout dimensions of the back of the hood liner on the IMPORTANT NOTE: For pro ventilation hood liners using wall. Dimensions will vary with the width of the hood an internal blower, refer to installation instructions liner.
- Page 10 All manuals and user guides at all-guides.com Pro Hood Liner Installation Hood Liner Installation Hood Wiring Connections BLOWER WIRING Due to the weight of the hood, be sure to have adequate assistance for installation. Before making electrical connections, make sure the electrical power is turned off at the service panel.
- Page 11 Internal, in-line and remote blowers are avail- IMPORTANT NOTE: Refer to specific installation instruc- able through your authorized Wolf dealer. For local dealer tions provided with each blower assembly for additional information, visit the find a showroom section of our mounting and wiring instructions.
- Page 12 Refer to the illustrations below for overall dimensions of Wolf in-line and remote blowers. Installation instructions Locate the blower so that the length of the duct run and shipped with each Wolf ventilation product provide number of elbows and transitions are kept to a minimum.
- Page 13 All manuals and user guides at all-guides.com Pro Hood Liner Installation wolfappliance.com/specs In-Line and Remote Blowers BLOWER WIRING 4) Locate the cord assembly provided with the blower. The cord assembly has two leads, black (L1) and white (neutral). Connect these leads to the leads from the Before making electrical connections, make sure the blower, black to black and white to white.
- Page 14 Gloves should be worn when installation has been completed correctly. handling filters. • Refer to the troubleshooting guide in the Wolf pro ventilation hoods use & care guide. INSTALL LIGHT BULBS • If the hood liner still does not operate properly, contact A suction-cup-style light bulb changer is provided with Wolf factory certified service.
-
Page 15: Service Information
Wolf Appliance, Inc. ©Wolf Appliance, Inc. all rights reserved. Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc. - Page 16 All manuals and user guides at all-guides.com WOLF APPLIANCE, INC. P. O. BOX 44848 MADISON, WI 53744 WOLFAPPLIANCE.COM 800.222.7820 817003 REV-A 3/2011...
