Wolf L282212I Installation Instructions Manual
Pro ventilation hood liners
Hide thumbs
Also See for L282212I:
- Planning information (9 pages) ,
- Installation instructions manual (16 pages)
Advertisement
Quick Links
Advertisement
Related Manuals for Wolf L282212I
Summary of Contents for Wolf L282212I
- Page 1 E N T I L A T I O N O O D I N E R S NSTALLATION NSTRUCTIONS...
- Page 2 Another footnote we would like to identify is IMPORTANT NOTE: This highlights informa- tion that is especially relevant to a problem- free installation. ® WOLF is a registered trademark of Wolf Appliance Company, Inc.
- Page 3 IMPORTANT NOTE: This installation must be L I S T O F M A T E R I A L S completed by a qualified installer or Wolf The following is a list of materials shipped authorized service center technician.
- Page 4 (except Model L282212I) are shipped without the blower assembly. Wolf internal, in-line and remote blower assemblies are available, refer to page 14. Use only a Wolf blower with the Pro hood liner IMPORTANT NOTE: Wolf recommends that the Pro ventilation hood liner be installed...
- Page 5 " (721) (572) Overall Depth " (572) OVERALL WIDTH OVERALL DEPTH Shipping Weight (shell only) 39–65 lbs Model L282212I (18–29 kg) Dimensions may vary to + – " (3). TOP WIDTH SUBTRACT 6" (152) FROM OVERALL WIDTH 1" (25) 3"...
- Page 6 Always use the interior measurements of the Pro Hood Liners decorative hood and measure in multiple places. Use the smallest dimensions to verify Model hood liner specifications. L282212I " (721) " (191) " (360) " (119) L342212 " (873) "...
- Page 7 Long duct runs, elbows and transitions will TO BOTTOM OF DECORATIVE HOOD reduce the performance of the hood liner. Wolf recommends the maximum linear duct run be no greater than 50' (15 m). The Pro hood liner has a vertical discharge.
- Page 8 Refer to the illustrations below for the location edge of the filters (Model L282212I only). of mounting holes for Pro hood liners and a Gloves should be worn to provide the cross-section of a typical installation.
- Page 9 I N S TA L L AT I O N I N S T R U C T I O N S I N S T A L L T H E H O O D L I N E R Attach the transition to existing ductwork IMPORTANT NOTE: If a backsplash is to be with sheet metal screws and duct sealing...
- Page 10 W O L F P R O V E N T I L A T I O N H O O D L I N E R S I N S T A L L W I R I N G Run a 120 V AC, 15 amp circuit (minimum) power cable from the service panel to the This ventilation hood liner must be...
- Page 11 UL or C/UL. Once the hood liner installation is complete, plug the blower power cord(s) into recepta- IMPORTANT NOTE: Wolf recommends cle(s) located near the center of the hood installing the internal blower to the rough-in liner shell.
- Page 12 Refer to the illustrations below and on the duct run and number of elbows and transitions following page for overall dimensions of Wolf are kept to a minimum. Wolf recommends the Optional acces- in-line and remote blowers. Also refer to the...
- Page 13 I N S TA L L AT I O N I N S T R U C T I O N S I N - L I N E A N D R E M OT E B L O W E R S B L O W E R W I R I N G Plug the cord assembly into the receptacle located near the center of the hood shell.
-
Page 14: Side View
Model L282212I. the Locator section into position (next to the grease cup on of our website, Model L282212I). Gloves should be worn to wolfappliance.com. R E M O T E B L O W E R S provide proper grip. - Page 15 Wolf troubleshooting steps: authorized service center. Verify that power is being supplied to the For the name and number of the Wolf ventilation hood liner. authorized service center nearest you, C O N T A C T...
- Page 16 W O L F A P P L I A N C E C O M PA N Y, I N C. P. O. B OX 4 4 8 4 8 M A D I S O N , W I 5 3 7 4 4 8 0 0 - 3 3 2 - 9 5 1 3 W O L FA P P L I A N C E .
