Model No. GZFI8013.3
Serial No.
Write the serial number in the
space above for future reference.
Serial Number
Decal
(inside tower)
Q
UESTIONS?
At FreeMotion Fitness, we are
committed to providing com-
plete customer satisfaction. If
you have questions, see HOW
TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
OWNER'S MANUAL
Visit our website at
www.freemotionfitness.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FREE MOTION EPIC STRENGHT GZFI8013.3
Summary of Contents for FREE MOTION EPIC STRENGHT GZFI8013.3
- Page 1 Model No. GZFI8013.3 Serial No. Write the serial number in the space above for future reference. Serial Number Decal (inside tower) OWNER’S MANUAL UESTIONS? At FreeMotion Fitness, we are committed to providing com- plete customer satisfaction. If you have questions, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 WARNING DECAL PLACEMENT . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the strength machine. 1. Read all instructions in this manual before 9. All users of the strength machine should be using the strength machine. Use the strength instructed to report any injury or strength machine only as described in this manual. -
Page 4: Warning Decal Placement
WARNING DECAL PLACEMENT The decals shown below have been placed on the strength machine in the indicated locations. If a decal is missing or illegible, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual to order a free replacement decal. -
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the EPIC STRENGTH ™ after reading this manual, see HOW TO CONTACT EXTENSION strength machine. The strength machine’s CUSTOMER CARE on the back cover of this manual. To stylish ergonomic design and never-before-seen fea- help us assist you, please note the product model tures improve upon traditional strength training. -
Page 6: Adjustments
ADJUSTMENTS This section explains how to adjust the strength machine. Make sure all parts are properly tightened each time the strength machine is used. Replace any worn parts immediately. ADJUSTING THE RESISTANCE To change the amount of resistance for your workout, insert the weight pin into the desired weight. - Page 7 ADJUSTING THE CAM RESISTANCE The CAM resistance can be adjusted to either a 1:1 or a 1:2 ratio to the weight stack. At a 1:1 ratio, the Pivot LIGHT resistance will be equal to the weight of the weight Plate Slot stack.
-
Page 8: Maintenance
MAINTENANCE For safe and trouble-free operation of your EPIC STRENGTH strength equipment, it is important to perform preventive maintenance on a regular basis. Make sure that all parts are properly tightened each time the strength machine is used. Replace any worn parts immediately. The strength machine can be cleaned with a cloth damp- ened with water and a mild, non-abrasive soap. - Page 9 MONTHLY • If there is not enough tension on the cable, the top weight will not be lifted immediately when 1. Grips: the leg lever is lifted. Ideally, the leg lever/cable • Check and replace as needed. should not move more than 1/2" from the rest- ing position before the top weight begins to be YEARLY OR AS REQUIRED lifted.
- Page 10 CABLE ADJUSTMENTS ADDITIONAL ADJUSTMENT Tower Pulley Adjustment– CAUTION: After making any cable adjustment, pull Tools required: 5/16" Allen wrench/hex key, 9/16" the leg lever using a light load and have someone open end wrench/spanner make sure that the cable is not derailed from a pulley or rubbing on a guard (see CABLE GUARDS on 1.
- Page 11 SERVICING THE WEIGHT STACK 8. Replace the top weight and weight pin on top of the weight stack. 9. Reattach the cable to the top weight coupler. For required parts, see HOW TO CONTACT CUS- 10. Clean and lubricate the guide rods by wiping TOMER CARE on the back cover of this manual.
-
Page 12: Cable Diagram
CABLE DIAGRAM The cable diagram shows the proper route of the cable. Use the diagram to make sure that the cable and the cable guards have been assembled correctly. If the cable has not been correctly routed, the strength machine will not function properly and dam- age may occur. - Page 13 NOTES...
-
Page 14: Part List
PART LIST—Model No. GZFI8013.3 R0405A If replacement parts are needed, or if parts are missing or damaged, see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual. Key No. Qty. Description Key No. Qty. Description Base 3/8" x 3/4" Button Screw Tower 1/2"... -
Page 15: Exploded Drawing
EXPLODED DRAWING—Model No. GZFI8013.3 R0405A... -
Page 16: How To Contact Customer Care
HOW TO CONTACT CUSTOMER CARE If you have questions after reading this manual, or if you require assistance, please contact Customer Care at the address and phone number listed below. Please be prepared to give the following information: • The MODEL NUMBER of the product (GZFI8013.3). •...
