exhart 10308 Assembly Instructions

Kinetic garden stake

Step 1:

Insert nut (C) into wheel (A).

LAY ASSEMBLY ON THE GROUND FOR THE FOLLOWING STEPS:

Step 3:

Insert fin (B) (the result of step 2) to top pole (D).

Wheel

Top Pole

Step 2:

Attach wheel (A) to fin (B) (the result of step 1) by

turning it to the right until it is firmly tightened.

Step 4:

Attach middle pole (E) to top pole (D) by turning it

to the right until it is firmly tightened.

Fin

Middle Pole (2)

Nut

Stake Base

Table of Contents

Need help?

Do you have a question about the 10308 and is the answer not in the manual?

Page 1 Wheel Top Pole Middle Pole (2) Stake Base Step 2: Step 1: Insert nut (C) into wheel (A). Attach wheel (A) to fin (B) (the result of step 1) by turning it to the right until it is firmly tightened. LAY ASSEMBLY ON THE GROUND FOR THE FOLLOWING STEPS: Step 3: Step 4:...
Page 2 90 degrees vertical to the ground. FOR DECORATIVE USE IN THE GARDEN. NOT TO BE GIVEN TO CHILDREN AS TOY. © 2020 Exhart - Chatsworth, CA 91311. Made in China / Fabrique en Chine. All Rights Reserved. For help please call 1-(800) 775-5503...
