NW-3500 108Mbps Wireless Network PC-Card
Product information
A: Power indicator LED
LED:
B: Link / Activity LED
Driver Installation
1
2
3
A
B
B blinks, A off:
Driver not installed
A, B alternatively blinking:
No connection
A, B blinking together:
Connection
Start notebook.
Installation in Windows XP and 2000 could differ.
Place CD.
Wait...
1
UK
Advertisement
Related Manuals for Trust NW-3500
Summary of Contents for Trust NW-3500
- Page 1 NW-3500 108Mbps Wireless Network PC-Card Product information A: Power indicator LED LED: B blinks, A off: Driver not installed B: Link / Activity LED A, B alternatively blinking: No connection A, B blinking together: Connection Driver Installation Start notebook. Installation in Windows XP and 2000 could differ.
- Page 2 NW-3500 108Mbps Wireless Network PC-Card a) Click ‘Install driver’. b) Click ‘Next’. c) Click ‘Next’. d) Click ‘Next’. e) Click ‘Finish’. f) Click ‘Finish’ to reboot. g) Wait until Windows is restarted.
- Page 3 NW-3500 108Mbps Wireless Network PC-Card Insert card. Wait… Click ‘Next’ Note: Windows XP Service Pack 2: ‘New Hardware wizard’ starts, first choose ‘No, not this time’ and click ‘Next’ to continue. When ‘Windows driver signing’ warning, click: ‘Continue Anyway’. Click ‘Finish’...
- Page 4 NW-3500 108Mbps Wireless Network PC-Card Connecting to existing wireless network (wireless Internet) Double click icon in the right lower corner of the screen. Uncheck ‘Use Windows to configure…”. Click ‘OK’. Double click. Click ‘Site Survey’.
- Page 5 NW-3500 108Mbps Wireless Network PC-Card a) Click ‘refresh’. b) Find the network you want to connect. If you cannot find your network, click ‘refresh’ again or move closer. c) Check the ‘WEP’ column. No WEP d) Determine the network type e) Click ‘Connect’:...
- Page 6 NW-3500 108Mbps Wireless Network PC-Card WEP enabled Use the same settings as used in the access point router. Choose key length. Mostly 128 bits. Use HEX format. Input the key. Make sure it’s entered correctly; otherwise the connection will not work.
- Page 7 NW-3500 108Mbps Wireless Network PC-Card After a few seconds, the network should be connected. If not, check all settings or move closer. Note: When the network connects, but the network doesn’t work, check the network adapter settings in Windows. See Windows help.
- Page 8 NW-3500 108Mbps Wireless Network PC-Card PC network: Setting up the first computer (Ad-Hoc) Double click icon in the right lower corner of the screen. Switch ‘Windows Zero configuration’ off. Click ‘OK’. Double click. Click ‘Configuration’.
- Page 9 NW-3500 108Mbps Wireless Network PC-Card Fill in: ‘SSID’: give your network a name. ‘Wireless Mode’: ‘Ad-hoc’. ‘Ad-Hoc band’: ‘11G’ ‘Channel’: select a channel, like 11. In France, use only 10-13. Click ‘Apply’. Your Ad-hoc network will start now. Set security: These steps are optional, but recommended.
- Page 10 NW-3500 108Mbps Wireless Network PC-Card Icon Meaning Driver not installed or disabled. No connection. Connected, but signal weak. Connected, good signal. Reminders Windows does not detect a new device after connecting the card. Check whether the driver has been installed correctly and whether the card has been inserted properly.
- Page 11 Use encryption (like WEP, WPA), otherwise everyone can use your network. Use WPA-PSK when possible. Use long and hard-to-guess passwords. Go to www.trust.com/14362 for up-to-date FAQs, drivers and instruction manuals. Safety • Do not open or repair this device. • Do not use a liquid cleaner or a spray, use a dry cloth.
- Page 12 DK, BE, IS, ES, GR, FR, FI, UK, NO, NL, AT, IE, CH, SE, IT, PT, DE, LU. In France, only channel 10-13 can be used. Go to www.trust.com/14362 for an updated list of the countries where the use of this device is permitted.
