Legacy Classic Furniture 9180-622 Assembly Instruction

Assembly Instruction
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts
that may have come loose inside the carton during shipment.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the assistance of
one or more persons in order to prevent personal injury and to insure parts are not damaged during the assembly
process. If dirty, clean finished parts with mild dishwashing liquid and water solution applied on damp cloth.
Cloth should not be excessively wet. Polish finish with soft cloth and an industry recognized furniture polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of furniture for
stain residue and rough surfaces and also check for staples or nails left after removing the packaging material. The
manufacturer will not be held responsible if preventative steps are not taken prior to installation.
(3) Unpack and dispose of all packing material but be careful not to throw away any assembly parts or
hardware. Read the instruction sheet and parts list carefully. Remove all staples and screws used for packaging
carefully using pliers and or screwdrivers to prevent injury and scratching or damaging flooring.
(4) During normal use everyday, screws, bolts, nuts and wooden plugs may loosen up. They should be
periodically inspected and re-tightened to prevent damage to the furniture and (or) personal property or cause
injury. Always check to be sure all hardware on this list and the above mentioned components is attached to the
furniture properly and kept tightened at all times.

PARTS List

Code Description
A Table Leg
B Column Base
C Mending Plate
D Table Top
E Table Leaf

Hardware List

See below
Hardware List
BOLT
L OCK
WA SHER
FL A T
WA SHER
WRENCH
NUT

Assembly Procedures:

Step 1: Lay out all parts and hardware. Make sure the quantity of each is correct.
Step 2: Rest the table top face down onto a clean soft flat surface such as a blanket and ensure that the surface is
clear of any objects that could scratch or damage the top. Remove the Mounting Plate (C) from the back
of the table top by using Wrench (4). Do not throw away the hardware when you remove the
Mounting Plate (C) as it will be used to attach this mounting plate back in the future steps.
Step 3: Attach the Table Leg (A) to the Column Base (B) by using Nut (5), Lock Washer (2) and Flat Washer (3),
and use Wrench (4) to tighten.
5/16" * 1-1/4"
5/16"
5/16"
5/16"
