Summary of Contents for Cayin CS-100A
- Page 1 V O L U M E SELECTOR POWER BIAS SELECTOR LINE LINE LINE M I N M A X VACUUM TUBE INTEGRATED AMPLIFIER CS- Vacuum Tube Integrated Amplifier User's Manual REV：1.1...
-
Page 2: Table Of Contents
Thanks for choosing CAYIN CS-100A Vacuum Tube Integrated Amplifier and please read the user's manual carefully before installation and operation. In order to prevent damage during transportation, the amplifier is packed with protective foams surrounding the tubes. Before installation and operation, please remove these foams to avoid any risks. -
Page 3: Package Contents
NOTE: CAYIN CS-100A Vacuum Tube Integrated Amplifier is designed and manufactured with our original parts and reaching the best results. We are not responsible for problems and damages caused by non-original parts replacement in the amplifier. Package Contents Please carefully check the package first and then open it. -
Page 4: Product Features
Product Features ◆ Eighty watts per channel in Class AB Ultra-linear mode, Fifty watts per channel in Triode mode, push pull amplifier design. ◆ 6SN7GTB voltage amplification stage, 12AU7EH phase invertor and voltage amplification, 12BH7EH voltage amplification and driver stage, KT88 or EL34 output tubes. ◆... -
Page 5: Specifications
◆ To reduce the risk of electric shock, do not remove the cover. ◆ No user serviceable parts inside. Refer servicing to qualified service personnel. ◆ To reduce the risk of fire or electronic shock, do not expose the unit to rain or moisture. -
Page 6: Maintenance
Maintenance NOTE: ◆ Use the soft dry cloth to clean up the chassis regularly. ◆ Do not use any chemicals for cleaning. V O L U M E SELECTOR POWER BIAS SELECTOR LINE LINE LINE M I N M A X VACUUM TUBE INTEGRATED AMPLIFIER CS- Warranty Service 1.This product is warranted for a period of twelve months beginning from the date of purchase. -
Page 7: Precautions
Precautions Connected to power socket INPUT OUTPUT TUBE SEL. RIGHT OUTPUT LEFT OUTPUT LINE LINE LINE SUB OUT VACUUM TUBE INTEGRATED AMPLIFIER MODEL : CS - Connected to AC INPUT SER.NO.: ZHUHAI SPARK ELECTRONIC EQUIPMENT CO.,L TD. Connection of power cord: Connect the speaker cables and signal cable first and then insert the power cord into the power socket. -
Page 8: Front Panel
You can hear sound from PRE-IN when PRE-IN 2. Power indicator indicator is on. Turn on the amplifier the power indicator will be Cayin CS-100A has memories and it will default last operation state when turning on. 3. Bias Selector Switch(A1、A2、A3、A4 、 B1、B2、B3、B4) 7.Triode/ Ultralinear... -
Page 9: Rear Panel
VACUUM TUBE INTEGRATED AMPLIFIER MODEL : CS - SER.NO. : ZHUHAI SPARK ELECTRONIC EQUIPMENT CO.,L TD. Diagram 2：CS-100A BACK 1. Signal Input Terminal Power tube replacing: 1. Refer to the "Tube Replacement" on page 11, Used for audio source input. -
Page 10: Top Panel
A zone, still , it would move for the voltage fluctuation. Diagram 3：CS-100A TOP 1.A1、A2、A3、A4、B1、B2、B3、B4:KT88/EL34 Turn the Tube SEL. to position KT88 on the rear panel, if you are going to use KT88 Tube. -
Page 11: Remote Control
Remote Control 1. Triode/Ultralinear Selector Installation 2. Audio Source Input Selector 1. Place the remote control upside up. Screw the rear 3. Mute Button cover open with the screwdriver. 4. Volume Control Selector 2. Pull out the battery case carefully (do not break the wires connected). -
Page 12: Installation
Installation Carefully read and follow the manual for installation: ◆ Do not place the machine near heat sources such as radiators, heat registers or other products that produce heat. ◆ In order to avoid being overheated please keep the unit's ventilation open. ◆... -
Page 13: Audio Connection
Audio Connection Connection method of CAYIN CS-100A with other audio equipments take pictures below for your reference. INPUT OUTPUT TUBE SEL. RIGHT OUTPUT LEFT OUTPUT LINE LINE LINE SUB OUT VACUUM TUBE INTEGRATED AMPLIFIER MODEL : CS - SER. NO. : ZHUHAI SPARK ELECTRONIC EQUIPMENT CO.,L TD. -
Page 14: Speaker Connection
Speaker Connection INPUT OUTPUT TUBE SEL. RIGHT OUTPUT LEFT OUTPUT LINE LINE LINE SUB OUT VACUUM TUBE INTEGRATED AMPLIFIER MODEL : CS - SER.NO.: ZHUHAI SPARK ELECTRONIC EQUIPMENT CO.,L TD. SPEAKER（R） SPEAKER（L） BLACK BLACK Check the impedance of your speakers: Attach the positive from your speaker to the 4 or 8 ohm terminal and the negative to the 0 ohm terminals separately. -
Page 15: Turn On
Turning On Before turning on the amplifier please make sure all connections are right and power supply is stable. • Turn on the amplifier, the power indicator will be on and the working indicator will keep flickering. • The working indicator will be on after 30 seconds. It means that the amplifier is working normally. If the working indicator is off, please turn off the power and contact with our local agent or our company. -
Page 16: Troubleshooting
Troubleshooting Please follow the instruction in the manual in order to keep the amplifier work in its best state. If wrongly operated and you thought that would be troubles please check according to following tip to look for the exact reason. -
Page 17: How To Install Vacuum Tubes
How to Install Vacuum Tubes How to Install 9-Pin Vacuum Tubes How to Install 8-Pin Vacuum Tubes Pin No. 9 Pin No.1 Positioning Pin Applicable vacuum tube: Applicable vacuum tube: 、5BK7、12BH7、 12AU7(ECC82)、12AX7(ECC83) KT150、 KT170、 KT88、 6550、 EL34、 6V6、 6SN7、 6SL7、 5AR4 12AT7(ECC81)、6922（ECC88), etc.
