Anthro AdjustaCart Assembly Instructions

Anthro Corporation | 10450 SW Manhasset Dr. | Tualatin, OR 97062
®
Toll-free: 800.325.3841 | Fax: 800.325.0045 | email: sales@anthro.com | anthro.com
Outside the U.S. | Tel: 503.691.2556 | Fax: 503.691.2409
*300-5053-00*
300-5053-00
Warranty:
This 48" Wide AdjustaCart has a Lifetime Warranty against manufacturing defects.
Technology Furniture and AdjustaCart are trademarks of Anthro Corporation. Anthro reserves the right to modify the design and specifications with-
out prior notice.
Notices:
48" Wide AdjustaCart
Assembly Instructions
Hello! Thank you for choosing Anthro.
Before beginning assembly of your
48" Wide AdjustaCart, please take a
moment to review the parts listed below
to verify that your shipment is complete.
02
03
Component list for part # AJ48xx/xx
01–48" Wide Base Tube ............Qty. 1 ............ 125-5012-xx
02– Caster Insert Screws.............Qty. 4 ...........325-5052-00
03– 1.75" Large End Caps ...........Qty. 2 ............ 175-5021-xx
04– Base Tube Screws..................Qty. 4 ............325-5000-00
05– 26.875" Vertical Legs ...........Qty. 4 ............ 125-5049-xx
06– Self-threading Screws .........Qty. 8 ............325-5010-00
07– Wood Screws ..........................Qty. 28 ........325-5106-00
08– 48" Wide Recessed Shelf .....Qty. 1 ........... 100-6034-xx
09– Shelf Supports .......................Qty. 8 ............ 175-5060-xx
10– Shelf Clamps ...........................Qty. 8 ............ 175-5059-xx
11– Clamp Screws .........................Qty. 8 ............325-5086-00
12– 1.5" Small End Caps ..............Qty. 4 ............ 175-5020-xx
13– 48" Wide Adjusta Shelf ........Qty. 1 ............ 100-6164-xx
Anthro ® Corporation Technology Furniture ®
1-800-325-3841
SAVE THESE INSTRUCTIONS!
13
14
15
08
07
01
14– 48" Wide Caddy Shelf ..........Qty. 1 ............ 100-6162-xx
15– 48" Wide Adjusta MechanismQty. 1 .......225-5547-00
(The Adjusta Mechanism is packaged separately & requires
assembly)
The following Tools have been provided (but not shown
above):
Hex Driver 5 / ".............................Qty. 1.................375-5000-00
32
Hex Driver Bit / " ......................Qty. 1.................375-5003-00
5
32
(The Hex Driver Bit can be used in your electric drill)
Hex Key / " .................................Qty. 1.................375-5016-00
5
32
8 oz. Rubber Mallet ...................Qty. 1.................375-5022-00
3-Way Wrench .............................Qty. 1.................225-5196-03
All Screw quantities listed here are the minimum needed for
your Cart assembly. There may be a few extra Screws included,
which are not counted in the Parts List.
10450 SW Manhasset Drive Tualatin, Oregon 97062 anthro.com
12
10
11
09
06
05
04
Rev. D December 2014
