aspenhome I45-225L-BAR/STN LF Pier Assembly Instructions

aspenhome
ah
ITEM NO: I45-225L-BAR/STN
I45-225R-BAR/STN
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
225L
Step 1: Put the case backside down on a soft surface, Attach the legs
to the bottom of case by using 4 bolts(A), lock washers(B) and flat
washers(C). Turn the case to the upright position.
I45-225L
I45-225R
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/2
LF Pier
RF Pier
225R
I45-265B
I45-275B
STEP 2: Attach the LF pier and RF pier to the TV
backer. Take off one screw from each metal plate on the
back of LF pier, RF pier and swing it into an ideal
location as shown to the right. Then re-secure the metal
plate with screw to TV backer.
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
R

TOOLS REQUIRED (NOT PROVIDED)

PHILLIPS SCREWDRIVER
Components List: I45-225L/225R
Description
No.
Leg
1
Hardware List: I45-225L/225R
Description
No.
Bolt Ø5/16"*2-3/4"
A
Lock Washer Ø5/16"
B
Flat Washer Ø5/16" *3/4"
C
D Allen Wrench 4mm
Quantity
Sketch
4 PCS
Quantity
Sketch
4 PCS
4 PCS
4 PCS
1 PC
Locating Dowel
C
B
A
Case
D
Bottom
Leg
09-06-2017
