TCL PDP42U3H Service Manual page 9

ITEM DESCRIPTION
25-BFA471-M1X CAP. ELEC 470 UF 50V +/-20%
25-HCB220-M1X CAP. ELEC 22 UF 16V +/-20%
25-HCB470-M1X CAP. ELEC 47 UF 16V +/-20%
28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805
28-BB0222-KBX SMD CAP 0.0022UF 50V +/-10%
28-BB0223-ZFX SMD CAP. 0.022 UF 50V F 0805
28-BB0224-ZFX SMD. CAP 0.22UF 50V +80%/-20% 0805
28-BB0334-ZFX SMD. CAP 0.33UF 50V +80%/-20%
28-BB0474-ZFX SMD. CAP 0.47UF 50V +80%
28-BD0105-ZFX SMD CAP 1UF 25V +80-20%
28-XC0225-MTX TANTALUM CAP. 2.2 UF 16V +/-20%
33-GLN300-NTX CHIP BEAD 30 OHM +/-25%
33-SLL330-MTX FILTER SLF12565T-33M2R8
34-R100K2-10X COIL CHOKE SG9006 10UH +/-20%
36-371620-00X NETWORK FILTER NF0801
36-WID450-XX0 COIL WIDTH 45UH
40-DP4226-AMB2X P.C.B. AM BD
46-39299H-04X HS 4P 1007#26 500 EI-4Y/SCN-4Y
46-39445H-04X HS 4P 2547#24 200MM TJC3-4Y/SCN-4Y
46-CD015T-08L HS 8P 2547#24 150MM
47-SPK015-XX0 SOCKET WP4-4C
08-P42U3H-ANY ASS'Y-ANALOG BOARD
07-380FI5-NB3 TUNER TEDE9-289A
09-0BA982-ATX SMD.DIODE BA982-GS08
09-0BAV99-ATX HIGH SPEED DOUBLE DIODE BAV99
09-55C33V-DTX SMD.DIODE BZV55-C33
09-LL4148-ATX SMD. SWITCHING DIODE LL4148
09-RLZ8B2-DTX SMD. ZENER DIODE RLZ8.2B
10-1N4001-EBX DIODE 1N4001 (RECTIFIER)
11-SC3779-DBX TRANSISTOR 2SC3779D (RF AMPL)
12-BC846B-0BX TRANSISTOR BC846B
12-BC847A-0BX SMD TRANSISTOR BC847A (NPN)
12-BC857A-0BX SMD TRANSISTOR BC857A (PNP)
12-SK2158-0BX TRANSISTOR 2SK2158
13-0TDA91-78P IC TDA9178
13-00M24C-08B IC EEPROM 8K M24C08
13-0L7805-CVS +5V 1.5A IC L7805CV
13-L7808C-D2B IC L7808CD2T-TR
13-PT7825-MTB IC PTTM7825MT（5V）
13-MSP341-0TB IC MSP3410G(64PINS)
13-TDA918-1TB IC SM TDA9181T/N1 (PHSE) R
13-TDA932-1HB IC SM TDA9321H/N2 (PHSE) R
13-V212MV-64B IC MTV212MV64I MCU (WRITE)
18-FH0120-JLX RES. M.O. 12 OHM 3W +/-5%
19-AA0000-FTX SMD. RES 0 OHM 1/16W +/-1% 0603
19-AA0101-JTX RES. SMD 100 OHM 1/16W +/-5%
LOCATION
C652
C614
C649
C605;C606;C607;C608;C611;C619;C622;C623;
C624;C625;C626;C627;C628;C629;C633;C635;
C636;C641;C642;C647;C650;C654;C655
C601;C602;C603;C604;C610;C620
C609;C621
C638;C639;C644;C645
C618

-20% C640;C646
C612;C613;C615;C616;C617;C634
C630;C632
L608;L609;L606
L607
L602;L603;L604;L605
T1
L601
J3
J2
J1
J5
TU1
D131
D102
D101
D001;D002;D003;D004;D005;D006;D007;D008
D904;D905;D906;D910
D802
Q121
Q111
Q131;Q202;Q203;Q204;Q205;Q206;Q263;Q271;
Q272;Q281;Q902;Q905;Q906;Q912;Q913;Q914;
Q916;Q917
Q261;Q262
Q012;Q013
IC202
IC003
IC802
IC801
IC002
IC204
IC203
IC201
IC001
R801
R109;R140;R220;R224;R232;R238
R016;R019;R020;R021;R026;R031;R032;R106;
R107;R206;R207;R028;R212;R216;R217;R218;
R288;R284;R285;RN1;RN2
9
QTY.
1
1
1
23
6
2
4
1
2
6
2
3
1
4
1
1
1
1
1
1
1
1
1
1
1
1
8
4
1
1
1
18
2
2
1
1
1
1
1
1
1
1
1
1
6
21
