TCL PDP42U3H Service Manual page 14

ITEM DESCRIPTION
28-XC0106-MTX TANTALUM CAP.10 UF 16V +/-20%
28-XC0225-MTX TANTALUM CAP. 2.2 UF 16V +/-20%
28-XC0226-MTX SMD. CAP 22 UF 16V +/-20%
28-XC0475-MTX TANTALUM CAP. 4.7 UF 16V +/-20% B
28-YC0474-MTX SMD.CAP. 0.47UF 16V +/-20%
33-ELL339-KTX SMD. COIL 3.3 UH +/-10% 0805
33-ELN190-NTX CHIP BEAD 19 OHM +/-25%
33-ELN201-NTX CHIP BEAD 200 OHM +/-25%
33-GLN190-NTX CHIP BEAD 19 OHM +/-25% (3216)
40-P4226W-DIC6X P.C.B. DIGITAL
45-OSC13M-5Y0 CRYSTAL 13.5MHZ (SHORT FEET)
45-OSC14M-3N0 CRYSTAL 14.318MHZ
45-OSC16M-2Y0 CRYSTAL JAS16T 16.2M
45-OSC24M-5N0 CRYSTAL 24.576 MHZ
45-OSC27M-0Y3 CRYSTAL 27MHZ
46-0D018F-07B01 HS 7P 1007#26 180MM EI-7Y/SCN-7Y
46-33079W-04X PIN BASE *4 TJC3-4A
46-33079W-05X PIN BASE *5 TJC3-5A
46-33079W-06X PIN BASE *6 TJC3-6A
46-33079W-08X PIN BASE *8 TJC3-8A
46-35199W-04X CONN.PH-4A 4PIN PITCH=2.0MM
46-35199W-05X CONN.PH-5A 5PIN PITCH=2.0MM
46-35199W-10X CONN. PH-10 10PIN PITCH=2.0MM
46-39297H-12X HS 12P 1007#26 200 SCN-12Y
46-39519W-30X 30PIN BASE DF13-30DP-1.25V
46-39539H-30X 30PIN TO 31PIN LVDS 500MM
47-DVI001-KX0 DVI SOCKET KL-DIV024-04A
47-ICS003-XX0 IC JACK
47-RCA109-HX0 3P RCA SOCKET AV-3.2-3W-X1(R/B/G)
47-RCA123-XX0 RCA SOCKET AV-3.2-2W-G6
47-VGA002-XX0 VGA JACKET D-SUB-15WP
47-VGA008-KX0 VGA SOCKET KL-PC09M-02 (FEMALE)
48-TAC001-XX0 TACT SWITCH
67-387190-0A0 HEAT SINK
67-387190-1A0 HEAT SINK
67-387200-1A0 HEAT SINK
67-387200-3A0 HEAT SINK
71-AV0000-T02 BARCODE LABEL
08-P42U3H-DP2 ASS'Y-DISPLAY PART2
35-FB0101-00X FERR BEAD
35-FB0133-00X FERR. BEAD ZCAT3035-1330
4A-OPT42P-MS1 42"OPTICS FILTER
54-700150-000 SP0NGE BAR
54-807990-0U0 SPONGE
LOCATION
C10;C14;C15;C77;C81;C120;C124;C126;C206;
C218;C220;C225;C286;C291;C296;C332;C341;
C343;C348;C349;C351;C353;C354;C355;C357;
C359;C360;C361;C362;C363;C163;C396;C395;
C010;C391
C33
C83;C211;C214;C256;C257
C26;C208;C216
C24
L1;L2;L3;L13;L15;L17;L18
L26;L27;L23
FB1;FB001;FB2;FB002;FB3;FB003;FB9;FB11;
FB12;FB13;FB14;FB16;FB21;FB22;FB23;FB25;
FB26;FB28;FB29;FB31;FB32;FB33;FB34;FB35;
FB41;FB43;FB44;FB49;FB50;FB51;FB52;FB53;
FB54;FB55;FB56;FB57;FB58;FB59;FB301;FB302;
FB303;FB304
L4;L5;L6;L7;L21;L28
X1
U17
Y1
Y3
Y2
J2
J6;P3;CN002
J8
J7
J5
CN003
P7
CN001
P8
JH3
P6
FOR U34
P2
J4
P4
JDP1
SW1
FOR U18;FOR U12
FOR U13;FOR U20;FOR U21
FOR U11
FOR U4
14
QTY.
35
1
5
3
1
7
3
42
6
1
1
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
3
1
1
1
1
1
1
1
2
2
