Page 1
SERVICE MANUAL PDP42U3H 1. Caution………………………………………………….2 2. Specification…………………………………………….6 3. BOM List………………………………………………..8 4. Alignment Procedure………………………………….18 5. Block Diagram………………………………………..22 6. Schematic Diagram……………………………………23 7. Explode View Diagram………………………………..45 This manual is the latest at the time of printing, and does not include the modification which may be made after the...
Page 2
SCHNEIDER ELECTRONICS GMBH-GERMANY 1. CAUTION CA UTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UT ION : T O RE DUCE TH E RIS K OF CA U T ION ELECTR ICA L SHOCK, DO NOT RE MOVE COVER (OR BACK).
Page 3
SCHNEIDER ELECTRONICS GMBH-GERMANY IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and Instructions marked on the audio equipment. 1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated. 2.
Page 4
SCHNEIDER ELECTRONICS GMBH-GERMANY PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
Page 5
SCHNEIDER ELECTRONICS GMBH-GERMANY OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
Page 6
2.Product Specification Environment Operation Temperature(℃) 0~45 Environment Temperature Store Temperature(℃) -10~60 Humidity Operation Humidity(%) 20~80% Store Humidity(%) 20~90% Air Pressure(kps) 86~106 Screen Parameter Screen Size 42“ Angle of View (H/V) 160°/160° Max. Resolution 852 x 480 Responsive Time ■16:9 □4:3 Ratio Image Size(mm x mm) 1.08 ×...
Page 11
ITEM DESCRIPTION LOCATION QTY. C231;C241;C243;C280;C910;C926;C934;C935; 28-RC0106-MAH SMD. CAP 10 UF 16V +/-20% C937;CN11;CN12;CN22;CN23;CN25 28-RC0107-MAH SMD. CAP 100 UF 16V +/-20% C803 28-RC0225-MAH SMD. CAP 2.2 UF 16V +/-20% C261 28-RC0226-MAH SMD. CAP 22 UF 16V +/-20% C902;C908;C911;C922;C931;C932 28-RC0335-MAH SMD. CAP 3.3 UF 16V +/-20% CN17 28-RC0475-MAH SMD.
Page 12
ITEM DESCRIPTION LOCATION QTY. 13-FLI230-00B IC FLI2300-BD 13-IC1084-CMB IC AIC1084-33CM 3.3V (TO-263) 13-0L7805-CVS +5V 1.5A IC L7805CV 13-LD1117-25B 2.5V REGULATOR IC LD1117S25(SOT-223) 13-LD1117-33B IC LD1117 3.3V U39;U42 13-ST232C-D0B IC ST232CD(SOP) 13-PT7825-MTB IC PTTM7825MT(5V) 13-PT7825-STB IC PTTM7825ST( 3.3V) 13-P80C32-UBB IC P80C32UBA(PLCC44) 13-PI5V33-0QB IC PI5V330Q (QSOP) 13-RT9172-N25...
ITEM DESCRIPTION LOCATION QTY. 54-703860-2U0 SP0NGE BAR 54-703860-9U0 SP0NGE BAR 54-708640-0U0 PVC INLAY 54-710460-0U0 SPONGE (2MMX10MMX960MM) 54-710470-0U0 SPONGE (2MMX10MMX555MM) 54-714150-0U0 SPONGE 54-714170-0U0 INSULATION BOARD 54-714370-0U0 PVC TRANSPARENT INLAY 54-714380-1U0 SP0NGE BAR 54-714490-0U0 PC SCREW POST 54-715620-0U0 SPONGE 960X8X4 MM FOR UP & LOW SUPPORT 54-715620-1U0 SPONGE 520X8X4 FOR LEFT &...
Page 16
ITEM DESCRIPTION LOCATION QTY. 67-S70636-0E7 SCREEN CAN 67-S71383-0E0 SHIELD CAN 67-S71384-0E7 SHIELD BOX (TOP) 57-10654X-00F TWIST TIE NY66 46-CC060F-06M01 5P UL2547#26 600MM 54-807980-0U0 SPONGE 54-808000-0U0 SPONGE 08-P42U3H-DP3 ASS'Y-PACKING PART+B380 41-UK3000-0JM EARPHONE SOCKET CHANGE RCA LINE 41-VK1800-9UU RF. LINE OF PIN 1800 +/-50MM 46-39286V-15X SIGNAL LINE 49-204260-BAT...
Page 17
ITEM DESCRIPTION LOCATION QTY. 46-39317H-02X01 HS 2P 1617#18 450MM 48-POW001-XX0 SWITCH POWER KDC-A11 B2 SW800 57-702240-0UG NYLON RIVET 64-B30060-103 M/C SCREW B 3 X 6 67-M70527-0G0 SWITCH BRACKET 4A-SCR42P-LG4 PDP 42" KK MODULE PDP42V69001 V8-PU3H00-01D01 SOFTWARE CODE FOR U16 V8-PU3H00-01D02 SOFTWARE CODE FOR U27 V8-PU3H00-01M02...
4. Alignment Procedure Flowchart of alignment procedure: Voltage White VCO and AGC adjustment balance adjustment Adjustment ALIGNMENT PROCEDURE: D-mode: 1) Press “◀” key to reduce the volume to 0 and press “MUTE” key, then press “9”, “7”, “3”, “5”” continually to enter the factory mode. 2) Press ▼/▲...
Page 19
Press “3” to enter Page3: TV adjustment menu Press “4” to enter Page4: Geometry picture geometry adjustment menu Item DATA Item Default data BLK-STRC HB00-PAL NOLINER VB00-PAL VGAMMA HB00-NTS LINE VB00-NTS STEEP HPNL-PAL CORING VPNL-PAL COLDELAY HPNL-NTS YDELAY VPNL-NTS LOCK FREQ 471.25 I.
Page 20
and GCUT-11K, set the reading of the color analyzer to x=0.265±0.005, y=0.280±.0.005. Then measure the white side of the screen where the luminance is 100±5nit. By changing the value of GGAIN-11 and RGAIN-11, set the reading of the color analyzer to x=0.265±0.005, y=0.280±.0.005.
Page 21
III. ALIGNMENT PROCEDURE FOR BOX: 1. VCO Adjustment: 1) Apply the Color-Bar signal (80dB) to TV jack. 2) Repeatedly press “M” key to AUTO SEARCH menu. Press ▼/▲ to select MANUAL item to search the signal. After catching the program, select FINE item and adjust until the frequency displayed in OSD is identical with the input signal.
Page 22
ANALOG B1 B1_ANALOG (D-SUB 1 5 ) <Value> <Value> HSYNC1 HS_PB VSYNC1 VS_PB <Value> SDRAM2 SDRAM3 PDP42U3 DIGITAL BOARD SCHEMATIC(JAGASM+FLI2300) <Value> <Value> Title PDP42U3H/26H DIGITAL BOARD(FLI2300+JAGASM) Size Document Number Custom TCL MULTIMEDIA R&D. -- YangHong Date: Friday, February 20, 2004 Sheet...
