TCL PDP42U3H Service Manual page 11

ITEM DESCRIPTION
28-RC0106-MAH SMD. CAP 10 UF 16V +/-20%
28-RC0107-MAH SMD. CAP 100 UF 16V +/-20%
28-RC0225-MAH SMD. CAP 2.2 UF 16V +/-20%
28-RC0226-MAH SMD. CAP 22 UF 16V +/-20%
28-RC0335-MAH SMD. CAP 3.3 UF 16V +/-20%
28-RC0475-MAH SMD. CAP 4.7 UF 16V +/-20%
28-RC0476-MAH1 SMD. CAP 47 UF 16V +/-20%
28-XC0225-MTX TANTALUM CAP. 2.2 UF 16V +/-20%
33-DLL220-KTX SMD. INDUCTOR 22 UH +/-10% 3225
33-ELL109-KTX SMD.COLL MGFI2012CIROKT
33-ELM100-KTX SMD. COIL 10UH +/-10% 0805
33-GLN121-NTX CHIP BEAD 120 OHM +/-25%
33-GLN301-NTX CHIP BEAD 300 OHM +/-25%
33-MLL101-MTX SMD. COIL 100 UH
34-A100K0-1IX COIL CHOKE 10 UH +/-10%
34-R102K7-0EX COIL 1000 UH +/-10%
34-R220J2-0EX COIL PL - 22 UH +/-5%
34-R220K2-1BX COIL CHOKE 22 UH +/-10%
38-350980-00X COIL I.F.T. 350980 FOR VCO
40-DP42U3-MAC4X P.C.B. BD
45-FIL4M5-0Y1 CERAMIC FILTER SFSH4.5MDB
45-FIL5M5-0Y1 CER FILTER 5.5MHZ
45-OSC12M-0Y2 CRYSTAL 12.0MHZ
45-OSC18M-4Y0 CRYSTAL 18.432M
45-OSC3M5-8N0 CRYSTAL 3.58MHZ (CL=20PF)
45-OSC4M4-3N0 CRYSTAL 4.43MHZ (CL=20PF)
45-SAW376-0K0 SAW FILTER K3760K
46-CD040T-04B HS 4P 1007#24/1185#26 400MM TJC3-4Y
46-FG010F-10001 HS 10P 2854#26 100MM PH-10Y/SAN-10Y
46-FG040T-04G HS 4P 1185#26 400MM PH-4Y/SAN-4Y
47-RCA111-HX0 3P RCA SOCKET AV-3.2-3W-X3
47-SVI008-XX0 S_VIDEO TERMINATOR
71-AV0000-T02 BARCODE LABEL
08-P42U3H-DIY ASS'Y-DIGITAL BOARD
09-0BAV99-ATX HIGH SPEED DOUBLE DIODE BAV99
09-LL4148-ATX SMD. SWITCHING DIODE LL4148
09-RLZ5B6-DTX SMD DIODE RLZ5.6BTE11
12-BC847A-0BX SMD TRANSISTOR BC847A (NPN)
12-BT3904-0BX SMD. TRANSISTOR MMBT3904LT1(NPN)
12-SK3019-0BX SMD. TRANSISTOR 2SK3019
13-024LC1-6BB IC 24LC16B
13-024LC2-1AP IC 24LC21A (WRITE)
13-LD1117-18B 1.8V REGULATOR IC LD1117S18TR
13-643220-T6B IC HY57V643220C(L)T-6
13-89C205-12P IC AT89C2051-24PI(DIP) (WRITE)
13-BGA388-00B IC BGA388
13-TFP401-APB IC TFP401APZP
13-63LVDM-83B IC THC63LVDM83R
13-EF4052-BTB IC HEF4052BT(D)
13-F040PC-90P IC 4M MX29F040PC-70(WRITE)
LOCATION
C231;C241;C243;C280;C910;C926;C934;C935;
C937;CN11;CN12;CN22;CN23;CN25
C803
C261
C902;C908;C911;C922;C931;C932
CN17
C101
C014;C102;C201;C225;C240;CN14;CN2;C806
C262
L201;L203;L204;L205
L121
L105;L208;L209;L903;L904;L905;L906;L907
FB1;FB2
LN1;LN2;LN3
L001;L101
L261
L102;L103
L202
L801
T201
Z262
Z261
X010
XN1
X204
X201
SAW1
JP2
JP3
JP1
P901;P903
P902
D4;D5;D6;D7;D8;D12;D13;D14;D15
D17;D18
D1;D2;D3;D9;D10;D11
Q7;Q18;Q001;Q002;Q003;Q19
Q1;Q2;Q3;Q4;Q5;Q6
Q13;Q14;Q15;Q16
U29
U27;U16
U40
U13;U20;U21
U35
U18
U26
U44
U8
U34
11
QTY.
14
1
1
6
1
1
8
1
4
1
8
2
3
2
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
9
2
6
6
6
4
1
2
1
3
1
1
1
1
1
1
