invotel AudioImage SX9100 User Manual

Problems
• Unplug the power connector wait 30 seconds then plug it back in.
1.
Recorder not working
make sure the connector is plugged in securely. Be sure to
or stopped working
observe the Green LED light turns ON.
• Be sure MX9000 card is inserted all the way into it's slot securely
• Check audio cord; try re-inserting it again, adjust the volume on
2. No audio
Recorder clockwise if needed to hear it. Check the volume on the
headset(if any) Be sure MX9000 card is inserted all the way into
it's slot securely
• Verify that the "Audio In" cord is plugged in securely Make sure
3. Audio Quality is poor
the source audio volume is not too loud, adjust the volume on
your audio source to correct the problem..

Warranty

This product is warranted against defects for a period of Three (3) years from the date of
original invoice. We will repair/replace the product with no charge for parts or labor within this
time. To obtain warranty service the product needs to be returned freight prepaid by the
customer with a copy of original invoice. This warranty does not apply if in the sole opinion of
Innovative Telecommunication Technology, the product has been tampered with or damaged
by lightning or any other acts of nature, misuse, neglect or unauthorized service.
EXCEPT AS SPECIFICALLY PROVIDED IN THIS AGREEMENT, THERE ARE NO OTHER
WARRANTIES, EXPRESSED OR OTHERWISE,INCLUDING, BUT NOT LIMITED TO ANY
IMPLIED WARRANTIES OR MERCHANTIBILITES OR FITNESS FOR A SPECIAL PURPOSE.
IN NO EVENT SHALL INNOVATIVE TELECOMMUNICATION TECHNOLOGY (INVOTEL) BE
LIABLE FOR LOSS OF PROFITS OR BENEFITS, INDIRECT, SPECIAL, CONSEQUENTIAL
OR OTHERWISE ARRISING FROM ANY BREACH OF THIS WARRANTY OR OTHERWISE.
®
1112 Montana Ave Suite 250 Santa Monica, CA 90403 USA
Toll-Free: 800-747-0708 Tel: 310-899-0078 Fax: 310-899-0227 http://www.invotel.com
All manuals and user guides at all-guides.com
Possible Cause / Solution
Insert the blank MX9000 "True Audio Card" into the slot as shown
•
to insert the card all the way into the blue connector)
Connect the audio source to the "Audio Input" jack of the SX9100 using
•
the provided 3.5mm to 3.5mm audio cord and "Y" patch connector.
Plug one end of the RCA audio cable into the Red RCA connector, Plug
•
the other end of the audio cable into your PBX phone system RCA
connector usually labeled as "MOH".
plug the other end into the Music-On-Hold adapter "Audio In" RCA connector instead
Adjust the "Volume" up by rotating the control clock wise as shown.
•
Plug the included AC adapter. (110V AC to 9V AC)
•
•
speakers
PC Speaker
OUT jack
CD player
Headset jack
"Y" patch connector
Volume Control
(Recording)
P4
REC
User Manual
AudioImage SX9100
™
Digital Audio System Player/Recorder
If you have regular Non-PBX telephones,
PC
SX9100
TELEPHONE
SYSTEM
MOH Port
Volume Control (Playback)
Max
Audio Out RCA
Audio Input
Recording LED
Rev 01
(be sure
.
MX9000 Card
DIGITAL
FLASH
MEMORY
Technology
110 V
9V AC
Power ON LED
