invotel DS9600P User Manual

Problems
• Unplug the power connector wait 30 seconds then plug it back
Player not working or
in. make sure the connector is plugged in securely. Be sure to
stopped working
observe the LED GREEN light turns ON.
• Be sure MX9008 or MX9017 card is inserted all the way down
into it's slot securely. The cut out on that card must be toward the
right see the picture in page 1
• Check audio cord; try re-inserting it again, adjust the volume if
needed.
Audio quality is poor
• Verify that the audio cord is plugged in securely,

Warranty

This product is warranted against defects for a period of Three (3) years from the date of
original invoice. We will repair/replace the product with no charge for parts or labor within this
time. To obtain warranty service the product needs to be returned freight prepaid by the
customer with a copy of original invoice. This warranty does not apply if in the sole opinion of
Innovative Telecommunication Technology, the product has been tampered with or damaged by
lightning or any other acts of nature, misuse, neglect or unauthorized service.
EXCEPT AS SPECIFICALLY PROVIDED IN THIS AGREEMENT, THERE ARE NO OTHER
WARRANTIES, EXPRESSED OR OTHERWISE,INCLUDING, BUT NOT LIMITED TO ANY
IMPLIED WARRANTIES OR MERCHANTIBILITES OR FITNESS FOR A SPECIAL PURPOSE.
IN NO EVENT SHALL INNOVATIVE TELECOMMUNICATION TECHNOLOGY LLC (INVOTEL)
BE LIABLE FOR LOSS OF PROFITS OR BENEFITS , INDIRECT, SPECIAL,
CONSEQUENTIAL OR OTHERWISE ARRISING FROM ANY BREACH OF THIS WARRANTY
OR OTHERWISE.
®
1112 Montana Ave Suite 250 Santa Monica, CA 90403 USA
Toll-Free: 800-747-0708 Tel: 310-899-0078 Fax: 310-230-5346 http://www.invotel.com
Possible Cause / Solution
Connect your Phone system MOH jack to Audio out jack.
•
Insert the MX9008 or MX9017 Flash Card into the slot as shown
•
insert the card all the way down into the blue connector)
Plug the included AC adapter. (110V AC to 9-12V)
•
LED Green light turns ON to indicate device is Playing
•
DS9600P
Volume
DIGITAL
P4
FLASH MEMORY
Technology
User Manual
DS
Invotel 9600P
Digital Audio System Player
with Digital Volume control
MX9008 Card
Phone system
MOH jack
AC adapter
AUDIO OUT
Rev 03
(be sure to
110 V
