Summary of Contents for Nakamichi NAM1630

  • Page 1 NAM1630 NAM1630...
  • Page 2 Warning & Precaution 1 EN Featuress 2 EN Accessory List 3 EN Wire Connection 3 EN Panel Operation 4 EN Remote Control Operation 4 EN Home Page Operation 5 EN Radio Operation 6 EN Radio Interface 6 EN Radio Area Selection 6 EN Automatic Search 6 EN...
  • Page 3 1 EN...
  • Page 4 1024 x 600 HD display in professional DSP 2 EN...

  • Page 5: Wire Connection

    WIRE CONNECTION Yellow Video input White Auxiliary left speaker input Yellow Video output Yellow Video output Auxiliary right speaker input Yellow Reverse camera Input White/ Green/ Black Yellow Black Black Grey Orange Green Purple/ Grey/ Brown/ Reverse SWC2 Purple White Black Black Purple/...
  • Page 6 NAM1630 4 EN...
  • Page 7 5 EN...
  • Page 8 6 EN...
  • Page 9 Name: NAM1630 1630 7 EN...

  • Page 10: Music Playback

    Adroid phone Mirrorlink MUSIC PLAYBACK 8 EN...
  • Page 11 9 EN...
  • Page 12 Click [ DSP ] to enter the DSP professional setting interface. Bass EQ DSP proessional instruction: 1. Click [ CH1~CH8 ] to switch the corresponding channel. There are 8 channels in total. 2. Click [ << ] to display " CH1~CH4 " channel click [ >> ] to display " CH5~CH8 " channel.
  • Page 13 Note: When 5.1 channels, 2 frequencies, or 3 are selected on the of DSP output frequency division, please install speaker according to the corresponding location of speaker distribution, and note that the audio output of RCA line defines socket docking (for the definition of RCA line , please refer to "AUDIO OUTPUT: Extension" of line connection in the manual).

  • Page 14: Position Settings

    Position Settings Click [ ] to enter the auto delay settings interface. Click the seat icon on the right to set the corresponding horn position. Delay Settings Click [ Manual ] to enter the manual delay settings interface. Click [-] or [+] corresponding to the horn to set the corresponding horn delay time.
  • Page 15 Click [　 ] to enter EQ and sound Settings screen. EQ equalizer can choose user1, user2, flat, bass, jazz, pop, classic, rock 8 sound modes. Note: 1. Choose flat, bass, jazz, pop, classic, rock sound, will not be able to change the corresponding frequency, gain and Q value.

  • Page 16: Focus Adjustment

    Focus Adjustment Click [　 ] to enter the audio and video setting interface. Click [ NUS OFF ] to turn NUS on or OFF. In this interface can adjust the main channel sound image, central sound image, surround sound image. The adjustment range is 0~16, click [ - ] or [ + ] to adjust.
  • Page 17 PC PROFESSIONAL DEBUGGING Main Menu Edit Section Main features: Save,Memory,Option,Mixer, Audio,NUS, SeakerNull and unconnected operations. Memory SpeakerNull Save Option Mixer Audio unconnected 1. Click "Save" to save the currently 4. Click " Mixer " to enter the mixing set frequency parameters interface, where the corresponding mixing input source can be entered Click on the "...
  • Page 18 PC PROFESSIONAL DEBUGGING Channel Equalizer Editing Area 6. Click the "NUS" pop-up window to open/close NUS SW and CEN SW; Channel equalizer editor area Main Adjustable main channel, middle function configuration: channel, surround channel. Current output channel equalization design, 14 frequency band equalization adjustable frequency, NUS SW CEN SW...
  • Page 19 PC PROFESSIONAL DEBUGGING 1. " GEQ " button: lick to select graphie ealization or parametic equalization. 2. "Reset EQ" button: lt is used to restore the parameters Reset EQ ofthe 14-band equalizer to the original pass-through mode (thefrequency of the equalizer, the value and Restore EQ the gain are restored to the initial value).

  • Page 20: Delay Unit

    PC PROFESSIONAL DEBUGGING 2. Sound adjustment: slid the scroll up 7. Out left and right joint and down to adjust the sound level adjustment: The joint of the of the channel, or input the value left and right channel data or scroll the mouse wheel in the of the output channel can sound input box to adjustthe sound...
  • Page 21 Beep Headlight detection RGBLED WHITE Study Again Before“Clear” 19 EN...
  • Page 22 20 EN...
  • Page 23 1024 x 600 21 EN...
