Options - Icom IC-A25 Basic Manual

• Spurious response rejection ratio:
IC-A25N/IC-A25E
VOR/COM More than 60 dB
WX More than 30 dB
IC-A25NE/IC-A25CE More than 70 dB
• Audio output power: More than 350 mW at 10% distortion
into an 8 ˘ load
* 1 For only the USA version.
* 2 When the GPS, Bluetooth, and Backlight are OFF.
* 3 Except operating frequency ±62.5 kHz in 25 kHz channel spacing.
* 4 Except operating frequency ±20.825 kHz in 8.33 kHz channel
spacing.
* 5 Except for operating frequency ±1 MHz.

■ Options

D Battery pack/Battery case
• BP-288
Li-ion
battery pack
Voltage: 7.2 V
Capacity: 2200 mAh (minimum),
2350 mAh (typical)
Battery life: Approximately 10 hours
• BP-289
battery case
Battery case with 6 AA battery cells.
D Charger
• BC-224 + BC-123S
rapid charger
To rapidly charge the battery pack.
D Belt clip and belt hangers
• MB-133
belt clip
• MB-96F, MB-96FL, MB-96N
belt hangers
ac adapter
SPECIFICATION AND OPTIONS
D Others
• FA-B02AR
antenna
• CP-20
cigarette lighter cable
Used when charging a battery pack through a 12 V or 24 V cigarette
lighter socket.
• OPC-2379
headset adapter
To connect your headset to the transceiver.
• HM-231
hand microphone
• RS-AERO1A*
Android TM application software for flight planning.
• RS-AERO1I*
iOS TM application software for flight planning.
• VS-3 Bluetooth ® *
headset
The Bluetooth headset with a [PTT] switch.
About the third party Bluetooth headsets:*
Icom has checked the PTT operation with some 3M Peltor headsets
such as the WS Headset XP, WS ProTac XP and WS Alert XP.
(Compatibility not guaranteed.)
Some options may not be available in some countries.
Ask your dealer for details.
*For only the IC-A25N and IC-A25NE.
Icom is not responsible for the destruction, damage to, or
performance of any Icom or non-Icom equipment, if the
malfunction is because of:
• Force majeure, including, but not limited to, fires, earthquakes,
storms, floods, lightning, other natural disasters, disturbances,
riots, war, or radioactive contamination.
• The use of Icom transceivers with any equipment that is not
manufactured or approved by Icom.
6
