Manual No.:ALPE11EN-G110-A1
ELEMENTI
!
!
IMPORTANT
SAVE THESE
INSTRUCTIONS
!
WARNING
For outdoor use only. DO NOT use
for cooking. DO NOT use under any
overhead enclosure.
R
C
US
!
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and
immediately call your gas supplier or fire department.
THE ART OF FIRE
Boulder fire table Owner's Manual
Gas type: Propane
If the information in this manual
is not followed exactly, a fire or
explosion may result causing
property damage personal injury
or loss of life.
Installation and service must be
performed by a qualified installer,
service agency or gas supplier.
Improper Installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
DANGER
OFG110
!
!
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use should not be
stored in vicinity of this or any other appliance.
WARNING
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
Save these instructions for
future reference. If you are
assembling this unit for someone
else, give this manual to him or her
to read and savefor future
reference.
!
WARNING
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ELEMENTI OFG110
Summary of Contents for ELEMENTI OFG110
- Page 1 Manual No.:ALPE11EN-G110-A1 ELEMENTI THE ART OF FIRE OFG110 Boulder fire table Owner's Manual Gas type: Propane IMPORTANT WARNING SAVE THESE If the information in this manual Read the installation, operation INSTRUCTIONS is not followed exactly, a fire or and maintenance instructions...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information -------------------------------------------------------------------- 3 Propane (LP) Dangers and Warnings ----------------------------------------------------------5 Hose & Regulator Assembly and Replacement ---------------------------------------------7 Parts List ----------------------------------------------------------------------------------------------8 Assembly Instructions ---------------------------------------------------------------------------- 9 Lighting Instructions ------------------------------------------------------------------------------13 Care and Cleaning --------------------------------------------------------------------------------14 Gas Component Checks ----------------------------------------------------------------------- 15 Troubleshooting -----------------------------------------------------------------------------------17 Warranty -------------------------------------------------------------------------------------------- 19 DANGER... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING FIRE TABLE IS FOR OUTDOOR USE ONLY IF YOU SMELL GAS • Shut off gas supply to the fire table. • Extinguish any open fame. • Do not try lighting any appliance. • Do not touch any electrical switch; do not use any phone in your building. •... - Page 4 IMPORTANT SAFETY INFORMATION • DO NOT use in an explosive atmosphere. Keep gas fire table area clear and free from combustible materials, gasoline and other flammable vapors and liquids. • This outdoor fire table is NOT to be operated by children. Young children should be closely supervised when in the vicinity of this outdoor fire table.
-
Page 5: Propane (Lp) Dangers And Warnings
The burner assembly cannot be replaced. Please contact Elementi at 800-678-7294 for technical support. • Place the hose out of the pathways where people may trip over it. Do not place the hose in areas where it may be subjected to accidental damage. - Page 6 LP gas cylinder. Never connect to an unregulated LP gas supply. For technical support contact Elementi at 800-678-7294 . • Hand turn the manual gas control valve. Never use tools. If the valve will not turn by hand, do not try to repair it.
-
Page 7: Hose & Regulator Assembly And Replacement
Fix or replace the hose as required before using the appliance. For assistance with repair or replacement of the hose, call Elementi at 800-678-7294 . Use only replacement parts from the manufacturer. -
Page 8: Parts List
PARTS LIST Fire Table LP Regulator and Hose Lava Rock Battery 8 / 20... -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS Install the AAA battery as shown in the diagram below. Battery not included. 9 / 20... - Page 10 ASSEMBLY INSTRUCTIONS 1. Place the tank seat on the ground and place a 20 lb. propane tank into the tank seat. 2. Tighten down the screw on the side of the tank seat to secure the propane tank. 60" Connecting the LP Gas Tank Disconnecting the LP Gas Tank Check to make sure there is no debris in the Make sure the valve on the LP gas tank is...
- Page 11 ASSEMBLY INSTRUCTIONS Place lava rock by hand. DO NOT dump bag out in to the tray to avoid clogging the burner with dust. Position the lava rock(13.2 lbs / 6 kgs) to a level about 1” above the top of the burner. Make sure that you do not block the igniter box with lava rock to ensure proper ignition.
- Page 12 Orifice is located If the burner pipe does not rest flush to the orifice please in this connection contact Elementi at 800-678-7294 for assistance. CHECKING FOR LEAKS Make a leak check solution by mixing 1 part dish washing soap with 3 parts water in a spray bottle.
-
Page 13: Lighting Instructions
LIGHTING INSTRUCTIONS Using the Ignitor 1. Read instructions before lighting. 2. Control knob must be in the “OFF”position. 3. Connect propane cylinder (See Manual). 4. Push and turn control knob counter clockwise to “Low”. 5. Press the igniter button repeatedly to light burner. 6. -
Page 14: Care And Cleaning
DO NOT tamper with this appliance. This is DANGEROUS and will void the warranty. Any part found to be faulty must be replaced with an approved part, WARNING confirmed by manufacturer. For technical support contact Elementi at 800-678-7294. General Care and Cleaning This outdoor fireplace should be cleaned regularly to ensure safe use and extend product life. -
Page 15: Gas Component Checks
GAS COMPONENT CONNECTION CHECKS If the burner will not light or stay lit, please perform the following checks. 1. Make sure the electrode wire is correctly connected. Both electrode wires must be fully inserted into the igniter box. the inner side Valve Thermocouple... - Page 16 GAS COMPONENT CONNECTION CHECKS 5mm / Thermocouple 0.196” Igniter Pin 3. Make sure that the igniter pin and thermocouple are correctly positioned. - The igniter pin should be pointed straight to the thermocouple. - The thermocouple should be positioned 5mm away from the burner tube. Valve Thermocouple Wire Thermocouple...
-
Page 17: Troubleshooting
-Call Elementi at 800-678-7294 for technical support. Possible Cause 4: Wire loose or disconnected. -Reference page 16, step 1, reconnect wire. Call Elementi at 800-678-7294. Possible Cause 5: Wire is shorting (sparking) between igniter and electrode. -Call Elementi at 800-678-7294 for support. - Page 18 TROUBLESHOOTING Problem: Sudden drop in gas flow, or a reduced flame height Possible Cause 1: Out of gas. -Refill your LP tank. Possible Cause 2: Excess flow safety device may have been activated. -Turn control knob to “OFF”, wait 30 seconds and light outdoor fireplace. If flames are still too low reset the excessive flow safety device by turning off the control knob and LP gas tank valve.
-
Page 19: Warranty
1 year from the date of purchase. In the event of such defects Elementi will, at its option, repair or replace the defective product. The foregoing is at the discretion of Elementi. - Page 20 ELEMENTI THE ART OF FIRE Ocean Rock USA LLC 1300 W. 9th St., Upland, CA 91786 www.elementifire.com info@elementifire.com Tel: 800-678-7294...
