Summary of Contents for Furniture Solutions OSBY 3Pc
- Page 1 INSTRUCTION MANUAL PRODUCT: OSBY 3Pc SETTING ITEM CODE: 18OSBBS3W MADE IN CHINA...
-
Page 2: Pre-Assembly Preparation
Do not over tighten the screws and bolts as this may damage the threads MINUTES PEOPLE REQUIRED ALLOW TIME For any assistance with assembly or missing parts please contact: Place of purchase or Furniture Solutions on below Customer Service (Australia) Phone– 1300794 188 Email– customerservice@furnituresolutions.com.au... -
Page 3: Parts List
PARTS LIST Side Table Code Description FAJ19307-S.LT Side Table Leg with thread FAJ19307-S.LH Side Table Leg with hole FAJ19307-S.B Side Table Rim FAJ19307-S.GP Glass Panel FAJ19307HW Flat Washer FAJ19307HW Spring Washer FAJ19307HW Short Bolt FAJ19307HW Long Bolt FAJ19307HW Cover Cap FAJ19307HW Tool... - Page 4 PARTS LIST Chair Code Description FAJ19307-C.LT Chair Leg with thread FAJ19307-C.LH Chair Leg with hole FAJ19307-C.B Chair seat & back rest FAJ19307-C.BC Chair back Cushion FAJ19307-C.SC Chair seat Cushion FAJ19307HW Flat washer FAJ19307HW Short Bolt FAJ19307HW Long Bolt FAJ19307HW Cover Cap FAJ19307HW Tool...
- Page 5 ASSEMBLY INSTRUCTIONS Foreword: Please read before you begin assembly (warning do not use power or battery drills) Upon opening carton you will need to organise your parts into like pieces IE: Side Table & Chair parts. This will assist in quicker assembly. The most difficult parts to separate will be the legs. Please follow below when sorting out parts.
- Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY-SIDE TABLE Please follow pre-assembly instruction on page.2. Step 1: As indicated by diagram below place side table rim [L] upside down, locate the threaded holes in base. Then Take leg [J] aline holes in base of leg with threaded holes in base as indicated in diagram angled across base, while a second person holds leg in place, take short bolt [F] together with spring washer [S] insert into holes, and by hand seat the thread correctly by turning 2-3 times, test if thread has gripped, lightly pull back on bolt.
- Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY-SIDE TABLE Please follow pre-assembly instruction on page.2. Step 2: Next position second leg [K] over the top and across as indicated in diagram. At intersection of legs fit long bolt [G] with spring washer [S] and also flat washer [E] insert thru hole and into threaded hole, seat thread correctly by hand, turn 2-3 times, ensure thread has gripped.
- Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY-CHAIR Please follow pre-assembly instruction on page.2. Step 1: As indicated by diagram below place chair frame [P] upside down, locate the threaded holes in base. Then Take leg [N] aline holes in base of leg with threaded holes in base as indicated in diagram angled across base, while a second person holds leg in place, take short bolt [F] together with flat washer [E] insert into holes, and by hand seat the thread correctly by turning 2-3 times, test if thread has gripped, lightly pull back on bolt.
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY-CHAIR Please follow pre-assembly instruction on page.2. Step 2: Next position second leg [O] over the top and across as indicated in diagram. At intersection of legs fit long bolt [G] with flat washer [E] insert thru hole and into threaded hole, seat thread correctly by hand, turn 2-3 times, ensure thread has gripped.
-
Page 10: Care And Maintenance
CARE & MAINTENANCE Varieties of materials are used in construction of “Outdoor” furniture range. All will require some form of maintenance to extend the life of finishes and general appearance. Please see below instruction unique to your chosen product. Osby Construction; Aluminium Frame: Tempered Glass: Textilene Rope:... - Page 11 CARE & MAINTENANCE Fabric Information; Fabrics used in outdoor product are not made of any special type of material; they do however use blends of common materials such as polyester, olefin & acrylic which perform best for intended purpose. These fabrics are not impervious to fading or mould, ensure cushions are always dry and put away when not in use.
- Page 12 WARNING SAFETY & ADVICE Please be aware materials used in your furniture are not impervious to neglect, acts of god, abuse, alcohol spills, improper use of chemicals such as bleach or any solvent based product, products are limited in design for residential use only and not suitable for commercial use.
- Page 13 To make a warranty claim, customers can either contact the retailer where the purchase was made or Furniture Solutions on contact details below. Proof of purchase will be required before proceeding with any claim. In the case of product defects providing photos may be able to speed up processing of the claim.
