36" GAS RANGE INSTALLATION INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
Dimensions and Clearance
Provide adequate clearance between
range and adjacent combustible surfaces.
3 6 "
(9 1 .4 cm )
4 7 ¾ "
)
(1 2 1 .3 c m
NOTE: Wiring diagram for this appliance is enclosed in this booklet.
Printed in Canada
INSTALLATION AND SERVICE MUST BE PERFORMED BY
A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
25 5/8"
(65.1 cm)
3 6 "
c m )
( 9 1 . 4
Minimum clearance on
either side of range
above 36" (91.4 cm)
height if a wall is
36"
(91.4 cm)
36" (91.4 cm)
(76.2 cm)
Minimum
5" (12.7 cm)
M A DD 1 B AKE ROIL B
L VEN O IGHT C LOCK VEN O IME T C OOK INUTE
O N/ O FF S LOW ARM W
O VEN C OOK H OLD &
LEX F K ITCHEN ELAY D REHEA T P
C LEAN T IMER S TART D OOR L OCKED S TOP ECIPE R
O N/ O FF C LEAR ECALL R
L OCKOUT O VEN
installed
36¼" (92.1 cm)
Between Cabinets
Figure 1
1
Appliances Installed in the
state of Massachusetts:
This Appliance can only
be installed in the state
of Massachusetts by a
Massachusetts licensed plumber
or gasfitter.
This appliance must be installed
with a 3 foot (36 in.) long
flexible gas connector.
A "T" handle type manual gas
valve must be installed in the
gas supply line to this appliance.
30"
Minimum to
18"
cabinets on
Maximum depth
(45.7 cm)
either side of
range
above range top
0" Min. Clearance
at rear of range
from the back wall.
P/N 318201766 (1302) Rev. B
Español – páginas 8-15
Wiring Diagram - pages 16
13"
(33 cm)
for cabinets
below cooktop
English – pages 1-7
