Speakman Neo VS-122 Instructions

INSTRUCTIONS FOR MODELS
VS-122
For additional assistance or service please contact:
SPEAKMAN
®
800-537-2107
customerservice@speakman.com
www.speakman.com
92-VS-122-01

TOOLS AND SUPPLIES

Pencil Level Phillips Phillips Hammer
Screwdriver Drive Bit
Drill Drill Bit Tile Drill Bit
ؼ" or Ø 1 " ؼ" or Ø
/
8

IMPORTANT

• Do not over-tighten any connections or damage
may occur.
• Be sure to read instructions thoroughly before
beginning installation.

SAFETY TIPS

Cover your drain to prevent loss of parts.

MAINTENANCE

Your new Speakman Product is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. The use of harsh
chemicals and abrasives on any of the Speakman custom
finish products may damage the finish and void the
product warranty. Please be sure to only use approved
cleaners. Please contact Speakman for any clarification
of acceptable cleaners.

WARRANTY

Warranty information can be found at:
www.speakman.com
1
Place Wall Mount in desired position on
wall. Location of Wall Mount is optional
but restricted by hose length. Wall Mount
should be vertical as shown. Mark
mounting screw locations onto wall
surface. Remove Wall Mount after marking
mounting locations.
1 "
/
8
2
If mounting directly to wood stud, the
included Plastic Anchors are not required.
Drill starter hole for Mounting Screws using
1/8" drill bit.
If mounting to tile or locations that require
Plastic Anchors, using a 1/4" drill bit, drill
holes in previously marked locations. Select
appropriate drill bit for surface being
mounted to.
OR
3
Insert Plastic Anchors into drilled holes and
tap lightly with hammer to fully insert/seat
into holes.
X2
4
Secure Wall Mount (1) with Mounting
Screws (2) provided (X2). Verify that Wall
Mount is aligned vertically.
X2
