Technical Data

Parameter
Front panel, W x H x D
Mounting depth
Front panel seal
Rear panel seal
Keyboard material
Reverse side
material
Weight
Serial port
RS422/RS485
Serial port RS232C
Flash memory for
application
Ethernet
USB
CF-slot
Real time clock
Real time clock
battery
Power consumption
at rated voltage
Display
Active area of
display, W x H
Fuse
Power supply
Ambient
temperature
Storage temperature
Beijer Electronics, MAEN773F
EXTER K100
382 x 252 x 6 mm
58 mm (158 mm including clearance)
IP 66
IP 20
Membrane switch keyboard with metal domes. Overlay
film of Autotex F157* with print on reverse side. 1 million
operations.
Powder-coated aluminum
2.5 kg
25-pin D-sub contact, chassis-mounted female with
standard locking screws 4-40 UNC
9-pin D-sub contact, male with standard locking screws 4-40
UNC
12 MB (incl. fonts)
Shielded RJ 45
Host type A (USB 1.1), max output current 500 mA
Device type B (USB 1.1)
Compact flash, type I and II
±20 PPM + error because of ambient temperature. Total
maximum error: 1 minute/month at 25 °C.
Temperature coefficient: -0.034±0.006 ppm/°C
CR2450 (UL and cUL: Sanyo or Panasonic)
Minimum lifetime: 3 years
Normal: 0.5 A
Maximum: 1.0 A
TFT-LCD, 800 x 600 pixels, 64K colors.
LED backlight lifetime at the ambient temperature of
+25 °C: >50,000 h.
211.2 x 158.4 mm
Internal DC fuse, 3.15 AT, 5 x 20 mm
+24 V DC (20 - 30 V DC). Power supply connector.
CE: The power supply must conform with the requirements
according to IEC 60950 and IEC 61558-2-4.
UL and cUL: The power supply must conform with the
requirements for class II power supplies.
Vertical installation: 0 ° to +50 °C
Horizontal installation: 0 ° to +40 °C
-20 ° to +70 °C
