Rolling Teacher Shield™ - RTS Series
Frame Assembly
1. Press bottom frame support into side frame supports, then fasten screw at bottom of frame sides.
2. Press top frame support halves into side frame supports.
3. Continue assembly instructions on next page.
1.
side frame
supports
bottom frame
support
2.
top frame
supports
raised indent
must face
outwards to
fit securely
Version: 1
Page 1 of 2
