Assembly instructions
Pantograph shutters
Read these instructions, observe the contents and the warning notes prior to
assembly. The information is very important for installation and correct use
of the material.
The pantograph shutter is a product for which not only the dimensional and
geometric tolerances, but also the straightness and parallel alignment of the
running and guide elements, must be adhered to without fail at the time of
installation in order to guarantee the trouble-free operation and performance
of the product.
Only trained personnel may mount and put the systems into operation.
Advertisement
Table of Contents
Related Manuals for Griesser Pantograph
Summary of Contents for Griesser Pantograph
- Page 1 The information is very important for installation and correct use of the material. The pantograph shutter is a product for which not only the dimensional and geometric tolerances, but also the straightness and parallel alignment of the running and guide elements, must be adhered to without fail at the time of installation in order to guarantee the trouble-free operation and performance of the product.
-
Page 2: Table Of Contents
Pantograph shutters Contents Notes regarding these instructions Validity of this manual 1.2 CE marking Used symbols Abbreviations Security 2.1 Safety and Warnings 2.2 Intended use Product description Exploded assembly drawing (external view) 3.2 Mounting accessories Marking Mounting Preparation for mounting 4.2 Installation tolerances... -
Page 3: Notes Regarding These Instructions
Pantograph shutters are designed in accordance with EU standards. 1.2 CE marking Griesser AST GmbH hereby declares that the pantograph shutters are in compliance with the basic requirements and other relevant provisions of EN standards. This is documented by the CE marking. -
Page 4: Security
Griesser AST GmbH does not accept liability for consequential damage. Griesser AST GmbH does not accept liability for damage caused by incorrect installation. Except for the actions described in the operating manual and the assembly instructions, the product... -
Page 5: Product Description
Pantograph shutters Product description Exploded assembly drawing (external view) 3.2 Mounting accessories Designation Rubber insert Suspension angle Scissors, short Scissors, long Sash Runner rail with fitted carriages Guide rails Version 01.18... -
Page 6: Marking
Pantograph shutters Marking Depending on the quantity, the components for the same pantograph shutter can be packed in several cartons. Mounting Preparation for mounting • Checking the installation dimensions The main dimensions must be checked according to the dimension sheet prior to installation.The installation tolerances according to the Technical Datasheet must be adhered to. -
Page 7: Fasteners
Pantograph shutters Fasteners In the installed condition, the pantograph shutter only meets the requirements of the given wind class when • the Runner rails, guide rails installed taking the permitted anchor plug extraction force into consideration • the processing guidelines of the used dowel pins were observed during assembly. -
Page 8: Installation Of The Runner Rail
Pantograph shutters Installation of the runner rail Draw position of the supply line in the runner rail and drill hole. Avoid sharp edges and burrs! Guide the supply line through the hole and suspend the runner rail. Determine the lateral clearance of the runner rail (X). -
Page 9: Installation Of The Guide Rail
Pantograph shutters Installation of the guide rail Fasten and center the guide rail symmetrically to the runner rail. Use appropriate fastening means! ca. 300 – 400 mm Countersunk head screws Ø 4 – 5 mm Clearance between wall and guide rail ca. - Page 10 Pantograph shutters Guide sash into the plain bearing bush of the fix clamp. Pivot sash under the carriage. Align scissors under the carriage. Engage sash in the quick-release coupling: Raise sash and insert quick-coupling bolt in the fix clamp above.
- Page 11 Pantograph shutters Mount end sash Secure scissors at top on last carriage with self-locking nut. Tighten nut slightly so that scissors can still move easily. Version 01.18...
-
Page 12: Annex
Pantograph shutters Annex 1. Schematic diagram of plug-type connection 2. Suspension angle Disposal Pantograph shutters must be disposed of in an environmentally friendly manner at the end of the product‘s service life! Griesser Sonnenschutz - Qualität seit 1882. Version 01.18...
