Assembly instructions
Wing shutters traditional
Read these instructions, observe the contents and the warning notes prior to assem-
bly. The information is very important for installation and correct use of the material.
Adhere to the described assembly steps and observe the notes and recommendations.
Only trained personnel may put the systems into operation.
Advertisement
Table of Contents
Related Manuals for Griesser WING SHUTTERS
Summary of Contents for Griesser WING SHUTTERS
- Page 1 Assembly instructions Wing shutters traditional Read these instructions, observe the contents and the warning notes prior to assem- bly. The information is very important for installation and correct use of the material. Adhere to the described assembly steps and observe the notes and recommendations.
-
Page 2: Table Of Contents
2. Security 2.1 Safety and Warnings 2.2 Intended use 3. Product description 3.1 Wing shutters Traditional 3.2 Wing shutters Marco de la cubierta protectora 3.2 Marking 4. Mounting 4.1 Preparation for mounting 4.2 Installation tolerances 4.3 Installation in an elevated area 4.4 Fasteners... -
Page 3: Notes Regarding These Instructions Page
The wing shutters have been approved for export and use in Austria. CE marking Griesser AST GmbH hereby declare that the external window shutters conform to the basic requirements and other relevant specifications contained in the EU standards. This is documented by the CE marking. -
Page 4: Security
Intended use Warranty claims are forfeited if damage is due to the non-compliance with the brochure or the attached document. GRIESSER AST GmbH does not accept liability for consequential damage. GRIESSER AST GmbH does not accept liability for damage caused by incorrect installation. -
Page 5: Product Description
WING SHUTTERS Product description Wing shutters Traditional (external view) Description Fastener Clamps Band Retention element Wing shutters Marco de la cubierta protectora (external view) Description Fastener Clamps / Band Retention element Version 02.15... -
Page 6: Marking
WING SHUTTERS Marking Depending on the quantity, the components for the same window shutter can be packed in several cartons. Mounting Preparation for mounting Checking the installation dimensions The main dimensions must be checked according to the dimension sheet prior to installation. -
Page 7: Installation In An Elevated Area
WING SHUTTERS Installation in an elevated area Fall protection Workers run the risk of falling when working at elevated heights. Suitable anti-fall guards must be used. Fasteners In the installed condition, the wing shutter only meets the requirements of the given wind class when ... -
Page 8: Pre-Installation Of Justierfix Window Shutters
WING SHUTTERS 4. Insert band (3). 5. Fasten set screw (5) and tighten screw (4). 6. Bring SystemFix to the proper position. 7. Tighten the set screw. Pre-installation of JustierFix window shutters (montage from inside) 1. Adjust offset and band length (note... -
Page 9: Installation Of Long Bands
WING SHUTTERS Attention K1: between 150 – 400 mm K2: Panel height minus K2 between 90 – 355 mm Installation of long bands Also mount the rivet for Model G in accordance with the diagram. Installation of the clamps 1. Clamp installation included concrete... - Page 10 WING SHUTTERS 2. Clamp installation included masonery, brick The drill holes are always made at a Variant 1 Variant 2 30°. Variant 1: Dowel installation Variant 2: Perforated sleeve (Hilti Hit) installation Clamp installation included WDVS Variant 1: Variant 1...
-
Page 11: Installation Of The Window Shutters
WING SHUTTERS 5. Fasten clamps and tighten. Attention Pay attention to the correct sealing of the clamps. Installation of the window shutters Set the window shutters in place and check that they function properly. 4.10 Installation of the shutter retention elements Select the screw-in depth so that the wings, when open, are parallel to the facade. -
Page 12: Installation Of The Shutter Fasteners
WING SHUTTERS 3. Door casement holder The door casement holder is pre- installed on the panels. Determine the position the wall faster and mark using the drill depth gauge. Drill holes and tighten shutter holder. Setting the retention element is done Attention appropriate to the surface. -
Page 13: Functional Check
WING SHUTTERS 4.12 Functional check 1. Check that the wings are parallel and at the same level and correct as necessary. 2. Correct the band position as necessary, adjust using the set screw. 3. Check the functioning of the lock. - Page 14 WING SHUTTERS Griesser AST GmbH Gewerbestrasse 17 6710 Nenzing Österreich / Autriche / Austria www.griessergroup.com Version 02.15...
