ASME A112.18.1 / CSA B125.1
ICC/ANSI A117.1
Models/Modelos/Modèles
65036 & 65436
Series/Series/Seria
Write purchased model number here.
escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
T E FLO N
For easy installation of your Brizo
faucet you will need:
• To Read aLL the instructions completely
before beginning.
• To Read aLL warnings, care, and maintenance
information.
Para instalación fácil de su llave
Brizo
usted necesitará:
®
• LeeR todaS las instrucciones completamente
antes de empezar.
• LeeR todoS los avisos, cuidados, e
información de mantenimiento.
Pour installer votre robinet Brizo
facilement, vous devez:
• LIRe toUteS les instructions avant de
débuter;
• LIRe toUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
U P
C
®
you may need/Usted puede necesitar/
articles dont vous pouvez avoir besoin:
®
®
SInGLe handLe LaVatoRy
VeSSeL FaUCet
LLaVe de aGUa de ReCIPIente PaRa
LaVamanoS de Una manIJa
RoBInet à Une manette PoUR
BaSSIn de ComPtoIR
T E FLO N
1
11/4/08 Rev. D
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Brizo 65036
Summary of Contents for Brizo 65036
- Page 1 Inscrivez le numéro de modèle ici. you may need/Usted puede necesitar/ articles dont vous pouvez avoir besoin: T E FLO N T E FLO N For easy installation of your Brizo ® faucet you will need: • To Read aLL the instructions completely before beginning.
- Page 2 1 3/8" (35 mm) Diameter 7 1/2" (191 mm) Max. Position Faucet (1) and gasket (2) on deck. option: If sink is uneven, use silicone under the gasket. Drill hole in finished deck per diagram. Hole location will vary depending on vessel sink. note: this faucet is intended for Secure faucet with washer (3) and nut (4).
- Page 3 Remove aerator (1) and turn faucet handle (2) to the full on mixed position. Turn on hot and cold water supplies (3) and flush water lines for one minute. Important: this flushes Make connections to water lines using the faucet connections (1) provided.
-
Page 4: Maintenance
maIntenanCe If faucet leaks from under handle: Remove handle and ensure bonnet (1) is tight. If leak persists: SHUT OFF WATER SUPPLIES. Replace valve cartridge (2)–Repair Kit RP50265. If faucet leaks from spout outlet: SHUT OFF WATER SUPPLIES. Replace valve cartridge (2)–Repair Kit RP50265. If faucet exhibits very low flow: Remove and clean aerator (3). - Page 5 Push Pop-UP with Overflow Control de rebose para desagües manuales Para los modelos de llaves de agua / grifos 65036, Brizo recomienda la instalación de un Renvoi mécanique à poussoir avec trop-plein desagüe manual RP6949570 (no se incluye) para los lavamanos con control de rebose o desagüe manual RP6949572 (no se incluye) para los lavamanos sin control de rebose.
-
Page 6: Cleaning And Care
This warranty excludes all industrial, commercial & business usage, whose purchasers are parts may be obtained by calling 1-877-345-BRIZO (2749) (in the U.S. and Canada) or by hereby extended a five year limited warranty from the date of purchase, with all other terms of writing to: this warranty applying except the duration of the warranty.
