- Page 1 USER'S MANUAL Hanging Egg Chair NP10111...
- Page 2 (Safety rope assembly) Lanyard assembly Muffler button Allen wrench Outer hexagon wrench...
- Page 3 Right foot plate Left foot plate Bottom straight tube Lower boom Upper boom Hanging basket Back cushion Seat cushion Safety rope assembly...
- Page 4 STEP 1: Use the screw (CC) to lock the right foot plate(A) and the left foot plate (B) together, do not tighten it.
- Page 5 STEP 2: Insert the bottom straight tube (C) into the right foot plate (A) and lock it together with the screw (EE); then insert the bottom straight tube (C) into the left foot plate (B) and lock it together with the screw (EE).
- Page 6 STEP 3: First use screws (DD) to lock the lower boom (D) on the foot plate(A) and the foot plate (B), and then use the screw (BB) to lock the lower boom (D) on the foot plate (A) and the foot plate (B), tighten all the screws.
- Page 7 STEP 4: Insert the upper boom (E) into the lower boom (D), and then lock and tighten it with the screw (AA), clamp the muffler (GG) on the upper boom (E) by rotating.
- Page 8 STEP 5: Hang the Lanyard (FF) on the basket, making sure it is in the middle.
- Page 9 STEP 6: Loosen the side connecting ring of the Lanyard assembly (FF) clockwise, hook the upper hook of the upper boom (E), and then lock the connecting ring counterclockwise; loosen the upper connecting ring of the safety rope on one side of the seat plate of the hanging basket (F) counterclockwise, and pass the safety rope through the lower boom (D), then use the connecting ring to lock it back to the seat plate and lock it clockwise.
- Page 10 STEP 7: Put the back cushion (G) and the seat cushion (H) on the hanging basket (F).
