Specifications
SkyVue Model C-NXG-4970-DS
C-NXG-4970-DS
Model:
Shown in Dark Brown w/optional 20 watt speaker bar.
Specifications
LED Screen High Bright LED Panel
Resolution 1920 x 1080
Response Time 12 ms
Contrast Ratio 1,300 : 1
Power Requirements AC 120V, 60HZ
Power Consumption 120W without speaker bar
140W with 20 watt speaker bar
Receiving System ATSC/NTSC
Television Weight 98 lbs. without speaker bar
103 lbs. with 20 watt speaker bar
F type analog (VHF/UHF/CATV) (Digital Air/Cable)
Ant/Cable
Component In Pr(C
Component
9 pin D-sub male connector
RS-232C
Photo / Music Modes
USB Input
Audio In Audio in (3.5 mm jack)
Audio Out Audio Out (3.5 mm jack)
Audio Output Coaxial SPDIF Audio Out
Analog RGB (PC) In
VGA/PC In
(15 pin mini D-sub female connector)
HDMI1 HDMI
HDMI2 HDMI (MHL)
HDMI3 HDMI
AV In Video(Y), Audio L (W), Audio R (R)
AV Audio Out Audio L (W), Audio R (R)
• The C-NXG-4970-DS has an optional 20 or 60 Watt Sound Bar
ALL NXG Series are equipped with an external air flow system
•
allowing filtered air to assist in keeping vital components cool.
2 Year Parts and Labor Warranty applies to all SkyVue NXG Series
•
Outdoor Televisions.
1) Satin Black, 2) White, 3) Dark Brown, 4) Slate Gray, 5) Sandstone, 6) Mint Green, 7) Hunter Green, 8) Terra Copper, 9) Patriot Blue
*All dimensions shown are for planning purposes only. We reserve the right to change materials and specifications without notice.*
Owner's Manual -
Model
Inputs:
), Pa(C ), Y
R B
SkyVue TV, 2218 Dawson Drive, Chester, SC 29706
www.skyvue.com
NXG-4970-DS | C-NXG-4970-DS
877.475.9883
Among SkyVue Outdoor TVs new lineup of NXG TVs is
the C-NXG-4970-DS . This 49" class model provides
customers with tremendous value when compared to
other mid-sized screen televisions. SkyVue's sunlight
readable full HD 1080p LED technology delivers the
most natural and vibrant picture quality available.
Protected by an all aluminum powder coated housing and
strengthened optically bonded anti reflective glass, the
NXG 700 nit Series is the preferred choice when seeking
maximum protection and premium clarity for your outdoor
television in direct sunlight.
43-7/8"
49"
Television Dimensions without speaker bar:
43-7/8" W x 25-7/16" H x 4-15/16" D*
Television Dimensions with speaker bar:
43-7/8" W x 28-7/16" H x 4-15/16" D*
(Optional table stand adds a minimal of 1.25" to height of television.)
• Internal Cooling System keeps the unit cool and dry in
temperatures up to 140º degrees F.
• Internal Thermostatically-Controlled Heater protects TV
temperatures as low as -24º degrees F.
• Innovative Water-tight Cable Entry System with pass-through
design keeps cables dry and allows for easy hook-ups.
• Anti-Glare/UV Coated screens, increases contrast and protects
the LED screen from sun's harmful rays
• Waterproof/Buoyant remote control included.
Don't forget to check out SkyVue's full assortment of
Mounts & Accessories for your Outdoor TV needs.
Available in nine designer colors.
1 2
5 6 7
TV C
4-15/16"
3 4
8 9
I I
