enabled DVI video device or PCs with VGA or DVI con-
nection.
(Continued on next page)
9. Component Video Jacks - This 3-cable connection
allows the chrominance (color) and luminance (bright-
Connections Cable Name
Speaker Bar Audio
(Female)
Speaker Bar Audio
Connections Cable to Use
HDMI OR HDMI-DVI
COAXIAL RF
Component
Composite
Terminal
QUALITY
Port
HD IMAGE
STANDARD
14
(Male)
Input to Select
HDMI
TV (CABLE/AIR)
VGA
VGA
YPBPR
AV1
Resolution
HDMI 1080i, 720p,
(Digital HD) 480p, 480i
ATSC/NTSC 1080i, 720p,
(Digital HD) 480p, 480i
VGA 1980 x 1080
(HD) or lower
Component 1080i, 720p,
(HD) 480p, 480i
Composite
480i Only
(non-HD)
Cable Name
HDMI or HDMI-DVI
Coaxial RF
VGA
Component
Composite
3.5 mm Mini-jack
RCA Audio
Coaxial SPDIF
AC Power
Typical Devices Used for This Input
Blue-Ray DVD Player,
HD-DVD Player,
HD Cable or Satellite Box,
HDCP devices
Antenna or Digital Cable (With out cable box)
PC or MAC with VGA Connection
Blue-Ray DVD Player,
HD-DVD Player,
HD Cable or Satellite Box,
HDCP devices,
Skyvue Speakerbar
Non High Definition Cable or Satellite Box, VCR, Older Game Consoles, Camcorder
