3. Connect the blue color connector to both your set-top box and Component blue connector port off the
back of your TV.
4. Connect the red color connector to both your set-top box and Component red connector port off the
back of your TV.
5. Obtain a RCA Audio Cable. Connect the white color connector to both your
set-top box and Component white connector port off the back of your TV to the right side of your green,
blue, red component connection.
6. Connect the red color connector to both your set-top box and Component red connector port off the
back of your TV to the right side of your green, blue, red component connection.
7. Turn on the TV and your set-top box.
8. Use the remote control's input button or the input button on the TV to switch to YPbPr.
Please Note :
1. Please refer to the set-top box's manual to make sure the settop box is configured
to output correctly to the TV.
2. This TV will turn off automatically if there's no signal present for more than 15
minutes.
Connecting with Composite
1. Make sure the power of the TV and your DVD/Blu-ray player is turned off.
2. Obtain a Yellow Video Cable. Connect the Yellow Video connector to both
your DVD/Blu-ray player and Composite's Yellow Video connector port off
the back of your TV.
3. Connect the white color connector to both your DVD/Blu-ray player and
Composite's white connector port off the back of your TV.
(Continued on next page)
4. Connect the red color connector to both your DVD/Blu-ray player and
Composite's red connector port off the back of your TV.
5. Turn on the TV and your DVD/Blu-ray player.
6. Use the remote control's input button or the input button on the right side of the TV to switch to AV
(CVBS).
Owner's Manual -
Model NXG-4970-DS | C-NXG-4970-DS
Located on Back of TV
TV I & C
nsTallaTIon onneCTIons
|
21
