Microwave Oven
MMC07S1AWW
MMC07S1ABB
Oven Capacity: 20Liter
120V~60Hz,
Input
Read these instructions
carefully before using your
microwave oven, and keep
it carefully.
If you follow the instructions,
your oven will provide you
with many years of good
service.
1050W
INSTRUCTION MANUAL
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMC07S1AWW and is the answer not in the manual?

Questions and answers

Summary of Contents for Midea MMC07S1AWW

  • Page 1 INSTRUCTION MANUAL Microwave Oven MMC07S1AWW MMC07S1ABB Oven Capacity: 20Liter 120V~60Hz, Input 1050W Read these instructions carefully before using your microwave oven, and keep it carefully. If you follow the instructions, your oven will provide you with many years of good...
  • Page 2: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO  EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allows soil or cleaner residue to accumulate on sealing surfaces.
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances basic safety precautions should be followed, including the following: WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: Read all instructions before using the appliance. 2.
  • Page 4 cord or plug, if it is not working properly, or if it has been damaged or dropped. 9. This appliance should be serviced only by qualified service personnel. Contact nearest authorized service facility for examination, repair, or adjustment. 10. Do not cover or block any openings on the appliance.
  • Page 5 17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.
  • Page 6: Grounding Instructions

    GROUNDING INSTRUCTIONS This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug.
  • Page 7 1. A short power supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord. 2. Longer cord sets or extension cords are available and may be used if care is exercised in their use. 3.
  • Page 8: Radio Interference

    RADIO INTERFERENCE Operation of the microwave oven may cause interference to your radio, TV or similar equipment. 2. When there is interference, it may be reduced or eliminated by taking the following measures: 1) Clean door and sealing surface of the oven 2) Reorient the receiving antenna of radio or television.
  • Page 9 UTENSILS CAUTION - Personal Injury Hazard Tightly-closed utensils could explode. Closed containers should be opened and plastic pouches should be pierced before cooking. See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not safe to use for microwaving.
  • Page 10: Materials You Can Use In Microwave Oven

    MATERIALS YOU CAN USE IN MICROWAVE OVEN UTENSILS REMARKS Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Browning dish Incorrect usage may cause the turntable to break. Microwave-safe only. Follow manufacturer's instructions. Dinnerware Do not use cracked or chipped dishes.
  • Page 11: Materials To Be Avoided In Microwave Oven

    MATERIALS TO BE AVOIDED IN MICROWAVE OVEN UTENSILS REMARKS Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal Metal shields the food from microwave energy. Metal trim maycause arcing.
  • Page 12: Setting Up Your Oven

    SETTING UP YOUR OVEN ▲ Names of Oven Parts and Accessories Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray Turntable ring assembly Instruction Manual A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray E) Observation window...
  • Page 13 ▲ Countertop Installation Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged. Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not remove the light brown Mica cover that is attached to the oven cavity to protect the mag-netron.
  • Page 14: Installation

    INSTALLATION Select a level surface damage the oven. that provide enough (4) Place the oven open space for the as far away intake and/or outlet from radios and vents. TV as possi- ble. Operation of microwave 12 inch(30cm) 3.0 inch(7.5cm) OPEN oven may cause 3.0 inch(7.5cm)
  • Page 15: Operation

    OPERATION Control Panel and Features EN-15...
  • Page 16 ▲ 1.Power Level 11 power levels are available. Level Power 100 % 90 % 80 % 70 % 60 % 50 % 40 % 30 % 20 % 10 % 0 % Display PL10 ▲ 2.Clock Setting 1). Press " CLOCK "once, "00:00" will display 2).
  • Page 17 Example: to cook the food with 50% microwave power for 15 minutes. a. Press "TIME COOK" once. "00:00" displays. b. Press "1", "5", "0", "0" in order. c. Press "POWER" once, then press "5" to select 50% microwave power. d. Press "START/+30SEC. " to start cooking. Note: 1).
  • Page 18: Frozen Vegetable

    ▲ 8.POPCORN 1). Press " POPCORN " repeatedly until the number you wish appears in the display, "1.75", "3.0 " ,"3.5 " Oz will display in order. For example, press " POPCORN" once, "1.75" appears. 2). Press " START/+30 SEC. " to cook, buzzer sounds once. When cooking finishes, buzzer will sound five times and then turn back to waiting state.
  • Page 19: Memory Function

    ▲ 14.MEMORY FUNCTION 1). Press " 0/MEMORY " to choose memory 1-3 procedure. The screen will display 1, 2, 3. 2). If the procedure has been set, press " START/ +30 SEC. " to use it. If not, continue to set the procedure. Only one or two stages can be set. 3).
  • Page 20: Inquiring Function

    ▲ 17.INQUIRING FUNCTION 1). In cooking state, if the clock has been set, press " CLOCK ", the oven will display clock for three seconds. 2). In the microwave cooking state, press " POWER " to inquire microwave power level, and the current microwave power will be displayed. After three seconds, the oven will turn back to the previous state.
  • Page 21: Maintenance

    MAINTENANCE Troubleshooting Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY a. Electrical cord for oven is not a.
  • Page 24 EN-24...
