For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
The following change was made since the owner's manual was printed:
•
The upper frame cover now has (4) 5" dust ports welded to it.
Aside from this information, all other content in the owner's manual applies and MUST be read and under-
stood for your own safety. IMPORTANT: Keep this update with the owner's manual for future reference.
For questions or help, contact our Tech Support at (570) 546-9663 or techsupport@grizzly.com.
New Frame Cover & Dust Ports
Old Frame Cover & Dust Ports
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
READ THIS FIRST
COPYRIGHT © DECEMBER, 2021 BY GRIZZLY INDUSTRIAL, INC.
#CS22199 PRINTED IN TAIWAN
Model G9980
***IMPORTANT UPDATE***
For Machines Mfd. Since 01/22
and Owner's Manual Printed 11/05
Revised Specifications
Product Dimensions:
Height ................................................. 65 in.
Shipping Dimensions:
Height ................................................. 77 in.
Main Specifications:
Other Related Information
Number of Dust Ports ..................... 4
Dust Port Size............................ 5 in.
Revised Parts
7101V2
REF
PART #
DESCRIPTION
7101V2 P99807101V2 UPPER FRAME COVER V2.01.22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G9980 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grizzly G9980

Summary of Contents for Grizzly G9980

  • Page 1 ***IMPORTANT UPDATE*** For Machines Mfd. Since 01/22 and Owner's Manual Printed 11/05 For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com The following change was made since the owner's manual was printed: • The upper frame cover now has (4) 5" dust ports welded to it.
  • Page 2 Grizzly or the shipping agent. You MUST have the original pack- Inventory (Figure 9) aging to file a freight claim.

  • Page 3: Air Line Installation

    Figure 11. Example of hose attached to port. Push regulator knob down until it snaps. Tug hoses to make sure they do not come off. Note: A tight fit is necessary for proper performance. Model G9980 (Mfd. Since 01/22)

  • Page 5: Read This First

    For Machines Mfd. Since January, 2014 & Owner's Manual Printed November, 2005 For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com The following changes were made to this machine since the owner's manual was printed: •...
  • Page 6 9139A-3 P99799139A-3 OL RELAY SCHN LR3D08 2.5-4A G9980 440V Conversion Kit PART # DESCRIPTION 9139AV2 P99809139AV2 440V CONVERSION KIT V2.09.10 9139A-1V2 P99809139A-1V2 OL RELAY SCHN LR3D325 17-25A V2.09.10 9139A-3 P99809139A-3 OL RELAY SCHN LR3D08 2.5-4A G9979/G9980 Update (Mfd. Since 1/14)

  • Page 7: Safety Instructions For Machinery

    Everyday ery. Never operate under the influence of drugs or eyeglasses are NOT approved safety glasses. alcohol, when tired, or when distracted. G9979/G9980 Update (Mfd. Since 1/14)
  • Page 8 Contact our debris. Make sure they are properly installed, Technical Support at (570) 546-9663. undamaged, and working correctly. G9979/G9980 Update (Mfd. Since 1/14)
  • Page 9 If normal safety pre- Failure to do so could result in serious per- sonal injury, damage to equipment, or poor cautions are overlooked or ignored, serious work results. personal injury may occur. G9979/G9980 Update (Mfd. Since 1/14)

  • Page 10: Section 2: Power Supply

    G9979: Full-Load Current Rating at 230V ..54 Amps Full-Load Current Rating at 460V ..27 Amps G9980: Full-Load Current Rating at 230V ..66 Amps Full-Load Current Rating at 460V ..33 Amps G9979/G9980 Update (Mfd. Since 1/14)

  • Page 11: Connection Type

    Nominal Voltage ....440V, 460V, 480V Extension Cords Cycle ............60 Hz Phase ............ 3-Phase Since this machine must be permanently con- Circuit Rating ........50 Amps nected to the power supply, an extension cord cannot be used. G9979/G9980 Update (Mfd. Since 1/14)
  • Page 12 (Set amperage dial to 3A) If you do not have three-phase power available for your wide belt sander, you must install a phase — For the G9980, order Part Number converter. P99809139AV2, which includes: Note: When using a phase converter, the power...
  • Page 13 Fuse 440V 220V 200V POWER SOURCE AMP METER POWER BRAKE EMG STOP FRONT CONVEYOR STOP LIMIT SWITCH EMERGENCY BRAKE EMG STOP PCR1 TABLE LIFTING PCR2 & LOWERING STOP START CONVEYOR BELT STOP START SANDING BELT G9979/G9980 Update (Mfd. Since 1/14)
  • Page 14 Replaces Page 48 220V Electrical Cabinet Wiring Diagram NOTICE To rewire for 440V operation, refer to 440V Conversion on Page 8. -10- G9979/G9980 Update (Mfd. Since 1/14)
  • Page 15 LOCK WASHER 5/16 6141 P99796141 HEX NUT 5/16-18 6139 P99796139 OSCILLATING AIR CYLINDER 50 X 4 6142 P99796142 CONNECTOR 1/4N X 1/4T X 90DEG 6140 P99796140 HEX BOLT 5/16-18 X 1-1/2 6306 P99796306 UNIVERSAL JOINT FORK -11- G9979/G9980 Update (Mfd. Since 1/14)
  • Page 16 9132 9122 9118 9119 9120 9136 9135 9123 9137 9133 9131 9115 9116 9117 9111 9104 9109 9129 9103 9107 9113 9111 9138 9105 9110 9102 9114 9106 9101 9112 9125 9108 9128 9127 -12- G9979/G9980 Update (Mfd. Since 1/14)
  • Page 17 9135 P99799135 6MM FLEXIBLE HOSE 9116 PH29339116 CONNECTOR 1/4N X1/8T 90º 9136 P99799136 6MM FLEXIBLE HOSE 9117 P99799117 THROTTLE VALVE 9137 P99799137 6MM FLEXIBLE HOSE 9118 P99799118 BRASS CONNECTOR 9138 P99799138 6MM FLEXIBLE HOSE -13- G9979/G9980 Update (Mfd. Since 1/14)
  • Page 98 Buy Direct and Save with Grizzly – Trusted, Proven and a Great Value! ® Visit Our Website Today And Discover Why Grizzly Is The Industry Leader! ® • SECURE ORDERING • ORDERS SHIPPED WITHIN 24 HOURS • E-MAIL RESPONSE WITHIN ONE HOUR...
