Problem Solving - Russell Hobbs Steam & Clean Pro RHDSM2001 Manual

PROBLEM
Trouble assembling/
disassembling steam
mop
Filling/Emptying
water tank

PROBLEM SOLVING

POSSIBLE PROBLEM
1. Difficult to attach mop
head.
2. Difficult to assemble
handle.
3. Difficult to attach mop
pad.
4. Difficult to attach
carpet glider.
1. Difficult to fill/empty
Note: Do not
water tank.
put detergent in the water
tank.
2. Difficult to fill/empty
detergent tank.
POSSIBLE SOLUTION
1. The main body of the product can be pushed down into
the nozzle of the mop head. Ensure the groove is aligned
correctly with the body. Refer to page 8 of the instruction
manual provided. Do not disassemble the heap after use.
2. Slot the handle into the top of the body of the steam
mop. You may need to push the stud on the handle
inwards to fully insert the handle. The stud should
protrude through the hole at the top of the body for it to
be secure. To remove the handle, push in the stud whilst
lifting the handle upwards.
3. Lay the mop pad on the floor and lift the steam mop
head, placing onto the pad. Make sure the blue microfibre
side of the pad is on the floor and attach the mop to the
other side. After use let the steam mop rest in the cooling
tray provided. To remove the mop pad hold you foot on
the edge of the pad and lift away the steam mop.
4. Lift the mop and place the head into the side of the
carpet glider that has space for the mop head. The mop
head rests in the glider and does not click into place.
1. From above the steam mop, grip the sides of the water
tank, located on the back of the main body, and pull
upwards to remove. Unscrew the cap on the water tank in
an anticlockwise direction and remove. You could use the
tap to fill, being careful not to overfill. Replace the cap on
the water tank and turn clockwise to secure. Turn the tank
upside down over the sink to let any water from the cap
drain out. Slide the tank back into the body, ensuring the
cap goes in the correct space. To refill, unplug and follow
the same procedure as above. To empty, use the same
procedure as filling but empty rather than fill the tank.
2. Follow the same procedure as the water tank, but
measure approximately 30ml of detergent and 150ml
water and add to the smaller detergent tank, located on
the front of the steam mop. Note: Ensure the detergent
dial is set to "close" when cleaning on carpets and use a
clean mop pad.
16
