ƒ Trusted Computing
Enables or disables Trusted Platform Module (TPM).
& PCIe Slot Configuration
Allows you to set the operation mode of the PCI Express slots to Gen 1, Gen 2, Gen 3, or Gen 4. Actual
operation mode is subject to the hardware specification of each slot. Auto lets the BIOS automatically
configure this setting. (Default: Auto)
& 3DMark01 Enhancement
Allows you to determine whether to enhance some legacy benchmark performance. (Default: Disabled)
ƒ AMD CBS
This sub-menu provides AMD CBS-related configuration options.
ƒ PC Health
& Reset Case Open Status
Keeps or clears the record of previous chassis intrusion status. (Default)
Disabled
Clears the record of previous chassis intrusion status and the Case Open field will
Enabled
show "No" at next boot.
& Case Open
Displays the detection status of the chassis intrusion detection device attached to the motherboard CI
header. If the system chassis cover is removed, this field will show "Yes", otherwise it will show "No". To
clear the chassis intrusion status record, set Reset Case Open Status to Enabled, save the settings to
the CMOS, and then restart your system.
& CPU Vcore/CPU VDDP/CPU VDD18/DDRVtt A/B/DRAM Channel A/B Voltage/PM_CLDO12/
+3.3V/+5V/CHIPSET Core/+12V/VCORE SOC
Displays the current system voltages.
ƒ Smart Fan 5
& Monitor
Allows you to select a target to monitor and to make further adjustment. (Default: CPU FAN)
& Fan Speed Control
Allows you to determine whether to enable the fan speed control function and adjust the fan speed.
Allows the fan to run at different speeds according to the temperature. You can adjust
Normal
the fan speed with System Information Viewer based on your system requirements.
(Default)
Allows the fan to run at slow speeds.
Silent
Allows you to control the fan speed in the curve graph.
Manual
Full Speed Allows the fan to run at full speeds.
& Fan Control Use Temperature Input
Allows you to select the reference temperature for fan speed control.
& Temperature Interval
Allows you to select the temperature interval for fan speed change.
& Fan/Pump Control Mode
Lets the BIOS automatically detect the type of fan/pump installed and sets the optimal
Auto
control mode. (Default)
Voltage mode is recommended for a 3-pin fan/pump.
Voltage
PWM mode is recommended for a 4-pin fan/pump.
PWM
- 34 -
